EC-630 < COMPONENT DIAGNOSIS > [HR16DE (WITHOUT EURO-OBD)] MALFUNCTION INDICATOR MALFUNCTION INDICATOR Description INFOID:0000000001693444 The Malfunction Indicator (MI) is located on the combination meter. Component Function Check INFOID:0000000001693445 1. CHECK MI FUNCTION 1. Turn ignition switch ON. 2. Make sure that MI lights up. Is the inspection result normal? YES >> INSPECTION END NO >> Go to Diagnosis Procedure INFOID:0000000001693446 1. CHECK DTC Check that DTC U1000 or U1001 is not displayed. Is the inspection result normal? YES >> GO TO 2. NO >> Perform trouble diagnosis for DTC U1000, U1001. Refer to 2. CHECK DTC WITH COMBINATION METER MWI-22, "CONSULT-III Function (METER/M&A)" . Is the inspection result normal? YES >> GO TO 3. NO >> Repair or replace. 3. CHECK INTERMITTENT INCIDENT GI-55, "Intermittent Incident" Is the inspection result normal? YES >> Replace combination meter. NO >> Repair or replace. SAT652J |
