EC-258 < COMPONENT DIAGNOSIS > [HR16DE (WITH EURO-OBD)] P1217 ENGINE OVER TEMPERATURE Check the coolant level in the reservoir tank and radiator. YES >> Go to NO >> GO TO 2. 2. PERFORM COMPONENT FUNCTION CHECK-II Confirm whether customer filled the coolant or not. Did customer fill the coolant? YES >> Go to NO >> GO TO 3. 3. PERFORM COMPONENT FUNCTION CHECK-III With CONSULT-III 1. Turn ignition switch ON. 2. Perform “COOLING FAN” in “ACTIVE TEST” mode with CONSULT-III. 3. Make sure that cooling fan motor operate at each speed (LOW/HI). Without CONSULT-III Perform IPDM E/R auto active test and check cooling fan motors operation, refer to . Is the inspection result normal? YES >> INSPECTION END NO >> Go to Diagnosis Procedure INFOID:0000000001677296 1. INSPECTION START Do you have CONSULT-III? Yes or No Yes >> GO TO 2. No-1 >> With A/C models: GO TO 4. No-2 >> Without A/C models: GO TO 5 2. CHECK COOLING FAN LOW SPEED OPERATION With CONSULT-III 1. Turn ignition switch ON. 2. Perform “COOLING FAN” in “ACTIVE TEST” mode with CONSULT-III and touch “LOW” on the CON- 3. Make sure that cooling fan operates at low speed. Is the inspection result normal? YES >> GO TO 3. NO >> Check cooling fan control circuit. Refer to 3. CHECK COOLING FAN HIGH SPEED OPERATION With CONSULT-III 1. Touch “HIGH” on the CONSULT-III screen. 2. Make sure that cooling fan operates at higher speed than low speed. Is the inspection result normal? YES >> GO TO 6. NO >> Check cooling fan control circuit. Refer to SEF621W |
