DLK-742 < REMOVAL AND INSTALLATION > [WITHOUT I-KEY, WITH SUPER LOCK] FRONT FENDER FRONT FENDER Removal and Installation INFOID:0000000001732058 REMOVAL 1. Remove the headlamp assemblies. Refer to EXL-84, "Removal and Installation" 2. Remove the cowl top cover (LH/RH). Refer to EXT-20, "Removal and Installation" . 3. Remove the front fender protector. Refer to DLK-742, "Removal and Installation" . 4. Remove the bolt and the front fender. CAUTION: While removing use a shop cloth to protect the vechicle body from damage. INSTALLATION Installation is in the reverse order of removal. CAUTION: • After installing, apply touch-up paint onto the head of the front fender bolts. and 1. Front fender 2 Bolt (LH 7 bolts required) (RH 8 bolts LIIA2657E |
