NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING

TM-623

< SYMPTOM DIAGNOSIS >

[5MT: RS5F91R]

C

E

F

G

H

I

J

K

L

M

A

B

TM

N

O

P

SYMPTOM DIAGNOSIS

NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING

NVH Troubleshooting Chart

INFOID:0000000001381677

Use the chart below to help you find the cause of the symptom. The numbers indicate the order of the inspec-
tion. If necessary, repair or replace these parts.

Reference page

TM-63

5

TM-63

5

TM-63

0

TM-63

5

TM-63

5

SUSPECTED PARTS
(Possible cause)

OIL (Oi

l

le

v

e

l is

 lo

w

.)

OIL (W

ro

ng

 oi

l.)

OIL (Oi

l

le

v

e

l is

 hi

gh

.)

GASKET (Damaged)

OIL SEAL (W

orn or

damaged)

O-R

ING

 (W

orn

 o

r

da

ma

ge

d)

SHIFT

 CONT

ROL

 L

INKAGE (W

orn

)



















SHIFT

 FORK (W

orn

)

GEAR (W

orn

 or

da

ma

ge

d)

BEARING (W

orn or damaged)

BAULK

 RING (W

orn

 or

da

ma

ge

d)

INSER

T SPRING (Damaged)

Symptoms

Noise

1

2

3

3

Oil  leakage

3

1

2

2

2

Hard to shift or will not shift

1

1

2

3

3

Jumps out of gear

1

2

2

TM-624

< PRECAUTION >

[5MT: RS5F91R]

PRECAUTIONS

PRECAUTION

PRECAUTIONS

Service Notice or Precautions for Manual Transaxle

INFOID:0000000001381678

CAUTION:

• If transaxle assembly is removed from the vehicle, always replace CSC (Concentric Slave Cylinder).

Return CSC insert to original position to remove transaxle assembly. Dust on clutch disc sliding
parts may damage seal of CSC and may cause clutch fluid leakage.

• Never reuse transaxle gear oil, once it has been drained.
• Check oil level or replace gear oil with vehicle on level surface.
• During removal or installation, keep inside of transaxle clear of dust or dirt.
• Check for the correct installation status prior to removal or disassembly. If matching marks are

required, be certain they do not interfere with the function of the parts they are applied.

• In principle, tighten bolts or nuts gradually in several steps working diagonally from inside to out-

side. If tightening sequence is specified, use it.

• Never damage sliding surfaces and mating surfaces.

PREPARATION

TM-625

< PREPARATION >

[5MT: RS5F91R]

C

E

F

G

H

I

J

K

L

M

A

B

TM

N

O

P

PREPARATION

PREPARATION

Special Service Tools

INFOID:0000000001381679

Tool number
Tool name

Description

ST27862000
Drift
a: 62.5 mm (2.461in) dia.
b: 49 mm (1.93 in) dia.

Installing differential side oil seal

KV32300QAC
(Renault SST: B.Vi.22-01)
Puller

Removing 5th main gear

KV32300QAD
(Renault SST: B.Vi.1000-01)
Puller

Removing 5th main gear

ST35300000
Drift
a: 45 mm (1.77 in) dia.
b: 59 mm (2.32 in) dia.

• Removing input shaft rear bearing
• Installing input shaft rear bearing
• Removing mainshaft rear bearing
• Installing mainshaft rear bearing

KV111038S0
Valve seat remover

Removing mainshaft front bearing

ST33061000
Drift
a: 60 mm (2.36 in) dia.
b: 47 mm (1.85 in) dia.

Installing mainshaft front bearing

ZZA0194D

SCIA1781J

SCIA1782J

ZZA0969D

ZZA0872D

ZZA0814D

TM-626

< PREPARATION >

[5MT: RS5F91R]

PREPARATION

KV40100900
Drift
a: 52 mm (2.05 in) dia.
b: 39.5 mm (1.555 in) dia.

Installing input shaft front bearing

ST33220000
Drift
a: 32 mm (1.26 in) dia.
b: 31.5 mm (1.240 in) dia.
c: 21 mm (0.83 in) dia.

Installing input shaft oil seal

KV32300QA
(Renault SST: B.Vi.1554)
Drift
a: 65 mm (2.56 in) dia.
b: 63 mm (2.48 in) dia.

Installing differential side bearing outer race

ST33052000
Drift
a: 22 mm (0.87 in) dia.
b: 28 mm (1.10 in) dia.

Removing differential side bearing

KV40104920
Drift
a: 21.7 mm (0.854 in) dia.
b: 44.7 mm (1.760 in) dia.

Installing differential side bearing

Tool number
Tool name

Description

NT084

ZZA1046D

SCIA1783J

ZZA0969D

ZZA0969D
