ROAD TEST
TM-487
< ON-VEHICLE MAINTENANCE >
[TYPE 2 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
M
A
B
TM
N
O
P
When lock-up duty becomes 94%. Refer to
XX-XX, "*****"
.
Does A/T hold lock-up condition for more than 30 seconds?
YES
>> GO TO 7.
NO
>> • Mark the box on the
XX-XX, "*****"
.
• GO TO
TM-151, "A/T Does Not Hold Lock-up Condition"
.
• Continue “Road Test”.
7.
CHECK SHIFT-DOWN (D
4
L/U TO D
4
)
Release accelerator pedal.
When lock-up duty becomes 4%. Refer to
XX-XX, "*****"
.
Is lock-up released when accelerator pedal is released?
YES
>> GO TO 8.
NO
>> • Mark the box on the
XX-XX, "*****"
.
• GO TO
TM-152, "Lock-up Is Not Released"
• Continue “Road Test”.
8.
CHECK SHIFT-DOWN (D
4
TO D
3
)
Decelerate vehicle by applying foot brake lightly.
Read gear position and engine speed. Refer to
XX-XX,
"*****"
.
Does engine speed return to idle smoothly when A/T is shifted from
D
4
to D
3
?
YES
>> 1.
Stop vehicle.
2.
Go to
TM-487, "Cruise Test - Part 2"
.
NO
>> • Mark the box on the
XX-XX, "*****"
.
• GO TO
TM-153, "Engine Speed Does Not Return to
.
• Continue “Road Test”.
Cruise Test - Part 2
INFOID:0000000001726686
1.
CHECK STARTING GEAR (D
1
) POSITION
1.
Push overdrive control switch. (OD OFF indicator lamp is off.)
2.
Move selector lever to “D” position.
3.
Accelerate vehicle by half throttle again.
Read gear position. Refer to
XX-XX, "*****"
.
Does vehicle start from D
1
?
YES
>> GO TO 2.
NO
>> • Mark the box on the
XX-XX, "*****"
.
• GO TO
TM-145, "Vehicle Cannot Be Started from D
.
• Continue “Road Test”.
2.
CHECK SHIFT-UP AND SHIFT-DOWN (D
3
TO D
4
TO D
2
)
1.
Accelerate vehicle to 80 km/h (50 MPH) as shown in the figure.
SAT959I
SAT495G
