Operation & Maintenance Manual──LG936L Wheel Loader

 20

the correct positions. Make sure all the control levers (or control handles) are easy to use.

z  Examine the foot brake valve and oil operation valve according to the user manual to make sure

that they are normal. Check whether the left turning and right turning is smooth at low speed.

z  Be sure the control lever of the manual brake valve is at rescission of braking state before moving

forward.

5 SAFETY DRIVING

5.1 Warning

z  The warning light should be turned on to warn the

other drivers on the road when the machine is

broken down or operating at a low speed.





5.2 Safety of self and Others

z  Develop good driving habits to ensure everyone’s

safety.

z  Sound the horn to ensure safety before moving.
z  Be sure there are no people or blockage on the left

and right side.

z  Check the brakes on dry and firm, level ground.


z  Do not put an arm or foot on the working equipment or extend outside the machine.





z  When driving on the level ground, adjust the lower

hinge of the arm working equipment to 400～

500mm(16～20in) above the ground.











Operation & Maintenance Manual──LG936L Wheel Loader

 21

z  Always warn people near the machine in all

direction by sounding the horn.

z  The door of the cab should be locked when driving.

Do not open the door while driving.









z  It is dangerous to pick up other people. No one

should sit on the machine body.

z  Never use the bucket as a people carrier.











z  Follow the traffic rules on the common roads. Pass

the crossing road quickly and do not block the road.







z  Drive on the side of the road and let the other

vehicles go first. Keep a proper distance from others.

z  Brake immediately and stop when the engine flameouts.


△

!



WARNING



z  Steering unit does not work when engine stops.

z  Emergency brake could hurt people!

z

It is dangerous to shift from forward to backward gear at high speed.

Never do this！





Operation & Maintenance Manual──LG936L Wheel Loader

 22

5.3 Full Load Transportation

z  Do not keep a full bucket in the high position when moving. Select the proper speed with a full

load during transport. Lower the bucket to contact the tilt block and run with proper height

(400~500mm above the ground), so that the center of

gravity can be lowered to insure driving smoothly.

z  Check the limit lifting weight of the loader. Never

overload, which may hurt the machine or people.

Shandong Lingong Construction Machinery Co. Ltd

assumes no responsibility for overload injury or

damage to equipment.





z  Do not drive, turn or brake suddenly and do not

detour.

z  Never suddenly stop or lower the working

equipment, which may throw out the materials from

the bucket or cause the loader to turn over.



5.4 Drive at Proper Speeds

z  Know the characteristics of the loader, and follow the actual conditions in the working area.

Drive at the proper speed. Select path of drive and method of machining to let the others know.

z  Keep a low speed so as to maintain control easily at all times.

z  Never drive fast, turn to brake suddenly on rugged, slippery or oblique ground.

z  Slow down when passing over rough or rugged ground with blocks around, which may cause

some problems in controlling the steering wheel. Loader may turn over if operated in the wrong

way.

z  Let the engine run smoothly; never drive at high speed.

5.5 Ensure Good Visibility

z  Slow the speed and sound the horn if necessary to let others know, and determine the proper

direction when the visibility is bad or at a narrow crossing.

z  Sand, dust, fog or storm may affect the visibility. Slow down when visibility is poor. When

visibility is not good, stop working until the weather cleans.

Operation & Maintenance Manual──LG936L Wheel Loader

 23

z  The loader is a special vehicle. Drive carefully when taking long parts which may block the

visibility. Carefully lift, go forward and backward,

and shift gears. Never let unauthorized people go

into the working area or give specific directions.

z  There may be some illusion about the height of the

ground and the distance at night, so keep the light on

and drive at proper speed.

z  Keep the front and rear headlight and working light

on when working in dark areas.



5.6 Pay Attention to Blockages

z  If there are blockages (roof of buildings or the door frame), keep the loader away from the

blockages when turning or passing.

z  Notice the environment. Slow down and check whether there are some blockages when turning or

going through a narrow passageway.

z  Operate carefully to prevent unstable loads when the ground is uneven and the load is not stable.


5.7 Driving in Dangerous Conditions

z  Do not operate when you are unsure about the

environment. Investigate the condition of the road,

the strength of the bridge, landform of the working

area and all geologic features before working.


z  Pay attention to the depth that the tires sink and the

braking effect on muddy or soft ground.

z  When working in water or swampland, prevent the

bottom of the axle housing from being soaked. Slow

down after passing through water or during rain.

Step on the brake pedal gently and alternately to let

the skid device dry after working in water or in rain.

z  The clay piled on the ground or near the canal is

usually soft. Never aloe a turn over caused by the

weight of the loader.
