LG936L Wheel Loader. Manual - part 3

Operation & Maintenance Manual──LG936L Wheel Loader



8

10. Warning to avoid noise














































13. Fuel tank



Located on fuel tank.



Located on the inner left back
upright column of the operator cab.



Located on the inner left back
upright column of the operator cab.



11. Wearing seat belt warning



Located on the left back upright column in inner operator cab



12. Warning of high voltage



14. No fire warning



Located on battery tank



Operation & Maintenance Manual──LG936L Wheel Loader



9


















































Located on both sides of engine hood.

15. Personal safety range



Located on both sides of engine hood.

16.Warning of machine reversing



Located on the lifting position of the
front and rear frames.

17.Start for lift



Located on filler of water tank of engine hood

Pay attention to steam or hot water ejection

18. Notice of hot water and oil



Located on vent-pipe of engine hood



19. Warning of high temperature



Operation & Maintenance Manual──LG936L Wheel Loader

 10


















































Located on right and left platform frames.

20. Notice for platform frame

Located on the hydraulic oil tank



21. Hydraulic oil tank



Located on the operation tank.



22. Notice for parking brake



Located on the steering position of front and
rear frames.

23. Danger of serious injury during
steering

24. Warning for starting



Located above the start bottom

Operation & Maintenance Manual──LG936L Wheel Loader

 11



2 SAFETY RULES

2.1 Safety Rules



z  Only trained and authorized people can be

permitted to operate and maintain the machine.







z  Follow all safety rules, precautions and instructions

when the machine is in operation or being

maintained.

z  Never operate machine when you are less than fully

alert. Don’t operate machine if you feel sick, or feel

sleepy after taking drugs or drinking alcohol when

your judgment may be impaised.





z  When working with another operator or with a

person on worksite traffic duty, be sure that all

people understand all hand signals that are to be

used.



z  Follow all the safety rules.



2.2 Safety Devices

z  Be sure all guards and covers are in their proper positions, and repair them when damaged.

z  Use the safety devices properly, such as parking brake switch and safety belt (if assembled).

z  Never remove any safety devices. Always keep them in good operating condition.

z  Improper use of safety devices could result in serious body injury are even death.
