3.
Inspect the battery carrier for damage caused by loss of acid
from battery. If acid damage is present, it is necessary to clean
area with a solution of clean warm water and baking soda.
Scrub area with a stiff bristle brush. Wipe clean with a cloth
moistened with ammonia or baking soda in water.
4.
Clean the battery, especially the top, with the same solutions
as described in step 3.
5.
Inspect the battery case and cover for cracks. If cracks are
present, battery must be replaced.
6.
Clean the battery post with a suitable battery post cleaning
tool.
7.
Clean the inside surfaces of the terminal clamps with a
suitable battery terminal cleaning tool. Replace damaged or
frayed cables and broken terminal clamps.
8.
Install the battery in the vehicle.
9.
Connect the positive and negative cables to the battery in the
order of mention.
10.
Tighten the clamp nut securely.
BATTERY CHARGING
M15401000011USA0000010000
When batteries are being charged, an explosive
gas forms beneath the cover of each cell. Do not
smoke near batteries on charge or which have
recently been charged. Do not break live circuits
at the terminals of the batteries on charge. A spark
will occur where the live circuit is broken. Keep all
open flames away from the battery.
Battery electrolyte temperature may temporarily be
allowed to rise to 55 °C (131 °F). Increase of
electrolyte temperature above 55 °C (131 °F) is
harmful to the battery, causing deformation of battery
cell, decrease in life of battery, etc.
CHARGE RATE
If the test indicator is white, the battery should be
charged as outlined below. When the dot appears or
when maximum charge shown below is reached,
charging should be stopped.
Charge Rate Chart
Battery
80D26L
Slow charging
5 amps 11 hours
10 amps 6 hours
Fast charging
20 amps 3 hours
30 amps 2 hours
BATTERY TEST
M15401000012USA0000010000
BATTERY TESTING PROCEDURE
STEP 1. Check the battery cables.
(1)
Remove the negative cable, then the positive
cable.
(2)
Check for dirty or corroded connections.
Q:Are the battery cables dirty or have corroded
connections?
YES:
Clean the battery cables. Then go to Step
2.
NO:
Go to Step 2.
BATTERY
54Aa-3
ON-VEHICLE SERVICE
