SUPPLEMENTAL RESTRAINT SYSTEM (SRS)

CIRCUIT DIAGRAMS

90-245

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE

ETACS-
ECU

FUSIBLE
LINK

36

RELAY BOX

ENGINE
COMPARTMENT

·AIR CONDITIONING
 SYSTEM
·CENTRAL DOOR
 LOCKING SYSTEM
·CONTROLLER AREA
 NETWORK (CAN)
·DAYTIME RUNNING LIGHT
·DOME LIGHT, LUGGAGE
 COMPARTMENT LIGHT AND
 IGNITION KEY HOLE
 ILLUMINATION LIGHT
·FOG LIGHT
·GLOVE BOX LIGHT
·HEADLIGHT
·IGNITION KEY REMINDER
 TONE ALARM
·IMMOBILIZER SYSTEM
·KEYLESS OPERATING
 SYSTEM (KOS)

·POWER WINDOWS
·REAR WIPER AND WASHER
·SUNROOF
·TAILLIGHT, POSITION LIGHT,
 LICENSE PLATE LIGHT AND
 LIGHTING MONITOR
 TONE ALARM
·THEFT-ALARM SYSTEM
·TIRE PRESSURE
 MONITORING SYSTEM (TPMS)
·TURN-SIGNAL LIGHT AND
 HAZARD WARNING LIGHT
·WINDSHIELD WIPER AND
 WASHER

IMMOBILIZER SYSTEM

CIRCUIT DIAGRAMS

90-246

IMMOBILIZER SYSTEM

36

FUSIBLE
LINK

MFI
RELAY

ETACS-ECU

CAN DRIVE
CIRCUIT

ANALOG
INTERFACE
CIRCUIT

ANALOG
INTERFACE
CIRCUIT

INTERFACE
CIRCUIT

IGNITION
SYSTEM

ENGINE
CONTROL
MODULE

ENGINE
COMPARTMENT

RELAY BOX

IMMOBILIZER SYSTEM

CIRCUIT DIAGRAMS

90-247

FRONT SIDE

CAN DRIVE
CIRCUIT

INTERFACE
CIRCUIT

5

FUSE

CAN DRIVE
CIRCUIT

INTERFACE
CIRCUIT

DATA LINK
CONNECTOR

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE

IMMOBILIZER SYSTEM

CIRCUIT DIAGRAMS

90-248

IMMOBILIZER SYSTEM (CONTINUED)

34

FUSIBLE
LINK

IGNITION
SWITCH (IG1)

30

RELAY BOX
(FUSE      )

ETACS-
ECU

IGNITION KEY
RING ANTENNA

ID
CODE

TRANSPONDER

<VEHICLES WITHOUT KOS>

IG1
RELAY

POWER
DISTRIBUTION
SYSTEM

WIRELESS CONTROL MODULE

·AIR CONDITIONING SYSTEM
·ANTI-LOCK BRAKING SYSTEM (ABS)
·ANTI-LOCK BRAKING SYSTEM (ABS) AND
 ACTIVE SKID CONTROL SYSTEM (ASC)
·AUTO-CRUISE CONTROL SYSTEM
·BRAKE WARNING LIGHT
·CHARGING SYSTEM
·CONTROLLER AREA NETWORK (CAN)
·DAYTIME RUNNING LIGHT
·DOOR AJAR WARNING TONE ALARM
·ELECTRIC CONTROLLED AWD
·FOG LIGHT
·FUEL WARNING LIGHT
·GLOVE BOX LIGHT
·HEADLIGHT
·HEADLIGHT AUTOMATIC LEVELING SYSTEM
·HEATED DOOR MIRROR
·HEATED SEAT
·IGNITION KEY REMINDER TONE ALARM
·INVECS-II 6A/T
·METER AND GAUGE
·MFI SYSTEM
·OIL PRESSURE WARNING LIGHT
·REAR WINDOW DEFOGGER
·REAR WIPER AND WASHER
·SEAT BELT WARNING TONE ALARM
·SHIFT LOCK MECHANISM
·SUNROOF
·SUPPLEMENTAL RESTRAINT SYSTEM (SRS)
·TAILLIGHT, POSITION LIGHT, LICENSE PLATE LIGHT
 AND LIGHTING MONITOR TONE ALARM
·THEFT-ALARM SYSTEM
·TIRE PRESSURE MONITORING SYSTEM (TPMS)
·TURN-SIGNAL LIGHT AND HAZARD WARNING LIGHT
·WINDSHIELD WIPER AND WASHER

:

NOTE
