METER AND GAUGE

CIRCUIT DIAGRAMS

90-109

INTERFACE CIRCUIT

CPU

FUEL
LEVEL
SENSOR
(SUB)

RHEOSTAT

FUEL
PUMP
MODULE

FUEL LEVEL
SENSOR
(MAIN)

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE

TONE
ALARM

2WD

4WD

·ODO/TRIP
·FUEL GAUGE
·TEMPERATURE
 GAUGE

LCD

BRAKE WARNING LIGHT, FUEL WARNING LIGHT AND OIL PRESSURE WARNING LIGHT

CIRCUIT DIAGRAMS

90-110

BRAKE WARNING LIGHT, FUEL WARNING LIGHT AND

OIL PRESSURE WARNING LIGHT

INTERFACE
CIRCUIT

CAN DRIVE
CIRCUIT

IG1
RELAY

IGNITION
SWITCH (IG1)

FUSIBLE
LINK

34

FUSIBLE
LINK

36

FRONT SIDE

POWER
DISTRIBUTION
SYSTEM

ENGINE
COMPARTMENT

RELAY
BOX

DATA LINK
CONNECTOR

NOTE

·AIR CONDITIONING SYSTEM
·CENTRAL DOOR LOCKING
 SYSTEM
·CONTROLLER AREA
 NETWORK (CAN)
·DAYTIME RUNNING LIGHT
·DOME LIGHT, LUGGAGE
 COMPARTMENT LIGHT
 AND IGNITION KEY HOLE
 ILLUMINATION LIGHT
·FOG LIGHT
·GLOVE BOX LIGHT
·HEADLIGHT
·IGNITION KEY REMINDER
 TONE ALARM
·IMMOBILIZER SYSTEM

·KEYLESS OPERATING
 SYSTEM (KOS)
·POWER WINDOWS
·REAR WIPER AND WASHER
·SUNROOF
·TAILLIGHT, POSITION LIGHT,
 LICENSE PLATE LIGHT AND
 LIGHTING MONITOR
 TONE ALARM
·THEFT-ALARM SYSTEM
·TIRE PRESSURE
 MONITORING SYSTEM (TPMS)
·TURN-SIGNAL LIGHT AND
 HAZARD WARNING LIGHT
·WINDSHIELD WIPER AND
 WASHER

:

THEFT-ALARM
SYSTEM

BRAKE WARNING LIGHT, FUEL WARNING LIGHT AND OIL PRESSURE WARNING LIGHT

CIRCUIT DIAGRAMS

90-111

INTERFACE
CIRCUIT

CAN DRIVE
CIRCUIT

INTERFACE
CIRCUIT

CAN DRIVE CIRCUIT

ETACS-
ECU

ANALOG
INTERFACE
CIRCUIT

ANALOG
INTERFACE
CIRCUIT

BRAKE
FLUID
LEVEL
SWITCH

ENGINE
CONTROL
MODULE

ENGINE OIL
PRESSURE SWITCH
LOW ENGINE
OIL PRESSURE: ON

·AIR CONDITIONING SYSTEM
·ANTI-LOCK BRAKING SYSTEM
 (ABS)
·ANTI-LOCK BRAKING SYSTEM
 (ABS) AND ACTIVE SKID
 CONTROL SYSTEM (ASC)
·CENTRAL DOOR LOCKING
 SYSTEM
·CHARGING SYSTEM
·CONTROLLER AREA NETWORK
 (CAN)
·DAYTIME RUNNING LIGHT
·DOME LIGHT, LUGGAGE
 COMPARTMENT LIGHT
 AND IGNITION KEY HOLE
 ILLUMINATION LIGHT

·SEAT BELT WARNING TONE ALARM
·SHIFT LOCK MECHANISM
·SUNROOF
·SUPPLEMENTAL RESTRAINT
 SYSTEM (SRS)
·TAILLIGHT, POSITION LIGHT,
 LICENSE PLATE LIGHT AND
 LIGHTING MONITOR TONE ALARM
·THEFT-ALARM SYSTEM
·TIRE PRESSURE MONITORING
 SYSTEM (TPMS)
·TURN-SIGNAL LIGHT AND
 HAZARD WARNING LIGHT
·WINDSHIELD WIPER AND
 WASHER

:

·FOG LIGHT
·GLOVE BOX LIGHT
·HEADLIGHT
·HEADLIGHT AUTOMATIC
 LEVELING SYSTEM
·HEATED DOOR MIRROR
·HEATED SEAT
·IGNITION KEY REMINDER
 TONE ALARM
·IMMOBILIZER SYSTEM
·INVECS-II 6A/T
·KEYLESS OPERATING SYSTEM
 (KOS)
·POWER WINDOWS
·REAR WINDOW DEFOGGER
·REAR WIPER AND WASHER

BRAKE WARNING LIGHT, FUEL WARNING LIGHT AND OIL PRESSURE WARNING LIGHT

CIRCUIT DIAGRAMS

90-112

BRAKE WARNING LIGHT, FUEL WARNING LIGHT AND OIL PRESSURE WARNING LIGHT (CONTIN-
UED)

FUEL
LEVEL
SENSOR
(SUB)

FUEL
PUMP
MODULE

FUEL LEVEL
SENSOR
(MAIN)

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE

2WD

4WD

INTERFACE
CIRCUIT

INTERFACE
CIRCUIT

CPU

CAN
TRANSCEIVER
CIRCUIT

LED DRIVE
CIRCUIT

COMBINATION
METER

ETACS-ECU

(FUSE     )

8

ETACS-ECU

(FUSE     )

9

(FUSE     )

12

ETACS-ECU

PARKING
BRAKE
SWITCH

LCD

FUEL WARNING/OIL
PRESSURE WARNING
