affected.  In  addition,  if  the  concentration  is
above  60%,  both  the  anti-freeze  and  engine
cooling  properties  will  decrease,  affecting  the
engine adversely. For these reasons, be sure to

maintain the concentration level within the
specified range.

｠

Do not use a mixture of different brands of anti-
freeze.

Coolant temperature °C (°F) and
specific gravity

Freezing
temperature

Safe

operating

temperature

Coolant
concentration
(specific volume)

10 (50) 20 (68) 30 (86) 40

(104)

50
(122)

°C (°F)

1.054

1.050

1.046

1.042

1.036

-16 (3)

-11 (12)

1.063

1.058

1.054

1.049

1.044

-20 (-4)

-15 (5)

1.071

1.067

1.062

1.057

1.052

-25 (-13)

-20 (-4)

1.079

1.074

1.069

1.064

1.058

-30 (-22)

-25 (-13)

1.087

1.082

1.076

1.070

1.064

-36 (-33)

-31 (-24)

1.095

1.090

1.084

1.077

1.070

-42 (-44)

-37 (-35)

1.103

1.098

1.092

1.084

1.076

-50 (-58)

-45 (-49)

Example

The safe operating temperature is -15°C (5° F) when
the specific gravity is 1.058 at the coolant temperature
of 20°C (68°F)

SCHEDULED MAINTENANCE TABLE

M10001000014USA0000010000

SCHEDULED MAINTENANCE SERVICE FOR EMISSION CONTROL AND PROPER VEHICLE
PERFORMANCE

Inspection and service should be performed any time
if a malfunction is observed or suspected.

No.

Emission

control

system maintenance

Service
intervals

Kilometers
in
thousands

120 144 168 192

Mileage in
thousands

105 120

Months

Fuel system (tank,
pipe

line

and

connection, and fuel
tank filler tube cap)

Check for leaks

Fuel hoses and pipes

Check condition

Air cleaner element

Replace

Evaporative emission
control system (except
evaporative emission
canister)

Check

for

leaks

and

clogging

GENERAL <BODY AND CHASSIS>

00-53

SCHEDULED MAINTENANCE TABLE

No.

Emission

control

system maintenance

Service
intervals

Kilometers
in
thousands

120 144 168 192

Mileage in
thousands

105 120

Months

Spark plugs

Iridium-
tipped type

Replace

Every 84 months or every 168,000 km (105,000
miles)

Intake valve clearance Inspect and adjust

If valve noise increases, adjust valve clearance

Timing belt

Replace

Every 168,000 km (105,000 miles)

Drive belts (for the
generator, water pump
and power steering
pump)

Check condition

Exhaust

system

(connection  portion  of
muffler,  muffler  pipes
and  converter  heat
shields)

Check and service

GENERAL MAINTENANCE SERVICE FOR PROPER VEHICLE PERFORMANCE

No.

General
maintenance

Service
intervals

Kilometers in
thousands

120 144 168 192

Mileage

thousands

105 120

Months

Engine oil

Change

Every 6 months or every 12,000 km (7,500
miles)

Engine oil filter

Replace

Every 6 months or every 12,000 km (7,500
miles)

Transfer oil

Check oil level and condition

Change

Engine coolant

Change

X at
first

Coolant

hoses

(radiator hose, heater
hose)

Inspect

Disc

brake

pads,

rotors

Inspect for wear

Every 12 months or every 24,000 km (15,000
miles)

Brake hoses

Check for deterioration or leaks Every 12 months or every 24,000 km (15,000

miles)

Ball joint and steering
linkage seals

Inspect for grease leaks and
damage

00-54

GENERAL <BODY AND CHASSIS>

SCHEDULED MAINTENANCE TABLE

No.

General
maintenance

Service
intervals

Kilometers in
thousands

120 144 168 192

Mileage

thousands

105 120

Months

Drive shaft boots

Inspect for grease leaks and
damage

Every 12 months or every 24,000 km (15,000
miles)

Suspension system

Inspect for looseness and
damage

Rear axle oil

Check oil level

Tires

Rotate

Every 12,000 km (7,500 miles)

Air filter

Replace

Every 18 months or every 24,000 km (15,000
miles)

NOTE:

*: This maintenance is recommended but is

not required to maintain the emissions warranty.

SCHEDULED MAINTENANCE UNDER SEVERE USAGE CONDITIONS

Maintenance should be carried out according to the
following table:

No. Maintenance

item

Service
intervals

Kilometers in
thousands

120

144

168

192

Mileage

thousands

105

120

Months

Air

cleaner

element

Replace

Every 12 months or every 24,000 km (15,000 miles)

Engine oil

Change

Every 3 months or every 6,000 km (3,750 miles)

Engine oil filter Replace

Every 3 months or every 6,000 km (3,750 miles)

Transmission
fluid

Change

X
chec
k

Disc

brake

pads, rotors

Inspect for wear

Every 6 months or every 12,000 km (7,500 miles)

Brake hoses

Check for deterioration or leaks Every 12 months or 24,000 km (15,000 miles)

Drive

shaft

boots

Inspect for grease leaks and
damage

Every 12 months or 24,000 km (15,000 miles)

Suspension
system

Inspect for looseness and
damage

Every 6 month or 12,000 km (7,500 miles)

Air filter

Inspect for clogging

Every 3 months or every 6,000 km (3,750 miles)

NOTE:

inspect and replace alternately

Replace

Severe usage conditions:

GENERAL <BODY AND CHASSIS>

00-55

SCHEDULED MAINTENANCE TABLE

Driving on dusty, rough, muddy or salt-spread
roads

Towing or police, taxi or commercial operation

Extensive idling and/or low speed operation

Repeated short-trip operation at freezing
temperatures (engine not thoroughly warmed up)

Extended use of brakes while driving

Driving in sandy areas

More than 50% operation in heavy city traffic
during hot weather above 32°C (90°F)

MAINTENANCE SERVICE

1. FUEL SYSTEM (TANK, PIPE LINE AND

CONNECTION, AND FUEL TANK FILLER TUBE

CAP) (CHECK FOR LEAKS)

M10001000016USA0000010000

ZC6033310000

Fuel main pipe

Fuel high-pressure tube

Check for damage or leakage in the fuel lines and connections.

2. FUEL HOSES (CHECK CONDITION)

M10001000017USA0000010000

Inspect the surface of fuel hoses for heat and mechanical
damage. Hard and brittle rubber, cracking, tears, cuts,
abrasions and excessive swelling indicate deterioration of the
rubber.

If the fabric casing of the rubber hose is exposed by cracks
and abrasions in the fuel system, the hoses should be
replaced.

3. AIR CLEANER ELEMENT (REPLACE)

M10001000018USA0000010000

ZC6038320000

The air cleaner element will become dirty during use, reducing
its effectiveness. Replace it with a new one.

Replacement of air cleaner element:

Unclasp the air cleaner housing.

Remove the air cleaner element and install a new one.

When clamping the air cleaner housing in place, be sure that
the cover is completely closed.

00-56

GENERAL <BODY AND CHASSIS>

MAINTENANCE SERVICE
