CONTROLLER AREA NETWORK (CAN)
TSB Revision
CIRCUIT DIAGRAMS
90-421
ASC-ECU
TRANSAXLE
CONTROL
MODULE
TRANSAXLE
CONTROL
MODULE
ABS-ECU
JOINT
CONNECTOR
(CAN3)
NOTE
:
:
:
:
:
:
CVT
6A/T
VEHICLES WITHOUT ASC
VEHICLES WITH
ELECTRONIC CONTROLLED AWD
VEHICLES WITH S-AWC
VEHICLES WITH ASC
