SEAT BELT WARNING TONE ALARM

TSB Revision

CIRCUIT DIAGRAMS

90-389

CENTER PANEL
UNIT

INTERFACE
CIRCUIT

PASSENGER'S
SEAT
BELT

DRIVER'S
SEAT
BELT

INTERFACE
CIRCUIT

INTERFACE
CIRCUIT

COMBINATION METER

RHEOSTAT

CPU

CAN TRANSCEIVER
CIRCUIT

LCD

(SEAT BELT)

(FUSE     )

12

ETACS-ECU

LED DRIVE
CIRCUIT

TONE ALARM

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER

PARKING BRAKE REMINDER TONE ALARM

TSB Revision

CIRCUIT DIAGRAMS

90-390

PARKING BRAKE REMINDER TONE ALARM

M1901033501042

FUSIBLE
LINK

34

IGNITION
SWITCH (IG1)

POWER
DISTRIBUTION
SYSTEM

ETACS-
ECU

IG1
RELAY

CAN
TRANSCEIVER
CIRCUIT

INTERFACE
CIRCUIT

CPU

TONE ALARM

LED DRIVE
CIRCUIT

COMBINATION METER

CAN DRIVE
CIRCUIT

INTERFACE
CIRCUIT

FRONT SIDE

JOINT
CONNECTOR
(CAN1)

·AIR CONDITIONING SYSTEM
·ANTI-LOCK BRAKING SYSTEM (ABS)
·ANTI-LOCK BRAKING SYSTEM (ABS)
 AND ACTIVE STABILITY CONTROL
 SYSTEM (ASC)
·CENTRAL DOOR LOCKING SYSTEM
·DAYTIME RUNNING LIGHT (DRL)
·DOME LIGHT, LUGGAGE
 COMPARTMENT LIGHT AND
 IGNITION KEY HOLE
 ILLUMINATION LIGHT
·FOG LIGHT
·GLOVE BOX LIGHT
·HEADLIGHT
·HEATED DOOR MIRROR
·HEATED SEAT
·IGNITION KEY REMINDER TONE
 ALARM <VEHICLES WITH KOS>
·IMMOBILIZER SYSTEM
·INVECS-II 6A/T
·INVECS-III CVT
·KEYLESS OPERATING SYSTEM
 (KOS)
·REAR WINDOW DEFOGGER
·REAR WIPER AND WASHER
·SEAT BELT WARNING TONE ALARM
·SHIFT LOCK MECHANISM
·SUNROOF
·SUPPLEMENTAL RESTRAINT
 SYSTEM (SRS)
·TAILLIGHT, POSITION LIGHT,
 REAR SIDE MARKER LIGHT,
 LICENSE PLATE LIGHT AND
 LIGHTING MONITOR TONE ALARM
·THEFT-ALARM SYSTEM
·TIRE PRESSURE MONITORING
 SYSTEM (TPMS)
·TURN-SIGNAL LIGHT AND HAZARD
 WARNING LIGHT
·WINDSHIELD WIPER AND WASHER

PARKING BRAKE REMINDER TONE ALARM

TSB Revision

CIRCUIT DIAGRAMS

90-391

PARKING
BRAKE
SWITCH

DATA LINK
CONNECTOR

CAN DRIVE
CIRCUIT

INTERFACE
CIRCUIT

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER

PARKING BRAKE REMINDER TONE ALARM

TSB Revision

CIRCUIT DIAGRAMS

90-392

PARKING BRAKE REMINDER TONE ALARM (CONTINUED)

ANALOG
INTERFACE
CIRCUIT

ANALOG
INTERFACE
CIRCUIT

CAN DRIVE
CIRCUIT

INTERFACE
CIRCUIT

ETACS-
ECU

ABS-ECU

ASC-ECU

INPUT SIGNAL

·FRONT WHEEL
 SPEED SENSOR
·REAR WHEEL
 SPEED SENSOR

NOTE

:
:

VEHICLES WITHOUT ASC
VEHICLES WITH ASC

JOINT
CONNECTOR
(CAN2)

JOINT
CONNECTOR
(CAN3)
