DIFFERENTIAL TSB Revision AUTOMATIC TRANSAXLE OVERHAUL 23D-91 >>C<< FINAL GEAR INSTALLTION CAUTION • The differential sub-assembly can be only assembled, but not disassembled. • Assemble the final gear to the differential assembly in the chamfer direction in the inside diameter of the final • Tighten bolts diagonally. Install the final gear on the differential assembly. Refer to the Tightening torque: 144 N ⋅m (106 ft-lb) No. of bolts 10 AK603460 |
