Mitsubishi Outlander GS45X. Manual - part 1611
23A-1
GROUP 23A
CVT
CONTENTS
GENERAL INFORMATION . . . . . . . .
SERVICE SPECIFICATIONS. . . . . . .
LUBRICANTS . . . . . . . . . . . . . . . . . .
DIAGNOSIS . . . . . . . . . . . . . . . . . . . .
DIAGNOSTIC TROUBLESHOOTING
FLOW . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
INTRODUCTION TO CVT DIAGNOSIS . . .
CVT DIAGNOSTIC TROUBLESHOOTING
STRATEGY. . . . . . . . . . . . . . . . . . . . . . . . .
DIAGNOSTIC FUNCTION . . . . . . . . . . . . .
HOW TO INITIALIZE CVT LEARNED
VALUE . . . . . . . . . . . . . . . . . . . . . . . . . . . .
LEARNING PROCEDURE FOR CVT
HYDRAULIC CONTROL. . . . . . . . . . . . . . .
FAIL-SAFE FUNCTION/BACKUP
FUNCTION . . . . . . . . . . . . . . . . . . . . . . . . .
ROAD TEST . . . . . . . . . . . . . . . . . . . . . . . .
TORQUE CONVERTER STALL TEST . . . .
HYDRAULIC PRESSURE TEST . . . . . . . . .
DIAGNOSTIC TROUBLE CODE CHART . .
TROUBLE SYMPTOM CHART . . . . . . . . . .
DIAGNOSTIC TROUBLE CODE
PROCEDURES . . . . . . . . . . . . . . . . . . . . . .
SYMPTOM PROCEDURES . . . . . . . . . . . .
DATA LIST REFERENCE TABLE. . . . . . . .
TCM TERMINAL VOLTAGE REFERENCE
CHART FOR TRANSAXLE OPERATION . .
OSCILLOSCOPE INSPECTION
PROCEDURES . . . . . . . . . . . . . . . . . . . . . .
SPECIAL TOOL . . . . . . . . . . . . . . . . .
Continued on next page
WARNINGS REGARDING SERVICING OF SUPPLEMENTAL RESTRAINT SYSTEM (SRS) EQUIPPED VEHICLES
WARNING
•
Improper service or maintenance of any component of the SRS, or any SRS-related component, can lead to
personal injury or death to service personnel (from inadvertent firing of the air bag) or to the driver and
passenger (from rendering the SRS inoperative).
•
Service or maintenance of any SRS component or SRS-related component must be performed only at an
authorized MITSUBISHI dealer.
•
MITSUBISHI dealer personnel must thoroughly review this manual, and especially its GROUP 52B - Supplemental
Restraint System (SRS) before beginning any service or maintenance of any component of the SRS or any
SRS-related component.
NOTE
The SRS includes the following components: SRS air bag control unit, SRS warning light, front impact sensors, air bag module,
side-airbag module, curtain air bag module, side impact sensors, seat belt pre-tensioners, clock spring, and interconnecting
wiring. Other SRS-related components (that may have to be removed/installed in connection with SRS service or maintenance)
are indicated in the table of contents by an asterisk (*).
