Removal steps



1.

Front fog lamp bezel



>>

A

<<

2.

Front fog lamp assembly

<<

A

>>

3.

Front fog lamp bulb

4.

Front fog lamp unit

FOG LAMP

CHASSIS ELECTRICAL

54A-157

REMOVAL SERVICE POINT

<<A>> FRONT FOG LAMP BULB
REMOVAL

CAUTION

Do not touch the bulb surface with bare hands or
dirty gloves. If the bulb surface (glass part) gets
dirty, immediately clean it with alcohol or thinner.
After drying completely, install the bulb.

INSTALLATION SERVICE POINT

>>A<< FRONT FOG LAMP ASSEMBLY
INSTALLATION

ACB05895

1

3

2

AB

Tighten the mounting screws to the specified torque
in the order shown.

Tightening torque: 1.2

± 0.7 N⋅m

REMOVAL AND INSTALLATION

M1542600300282

REAR FOG LAMP

ACB05602

ACB05838

AB

1

Section A – A

Claw

Rear bumper

2

3

4

1

Hook

A

A

Removal steps



<



<

A

>



>

1.

Rear fog lamp assembly

2.

Rear fog lamp socket

3.

Rear fog lamp bulb

4.

Rear fog lamp unit

Removal steps (Continued)

SIDE TURN-SIGNAL LAMP

CHASSIS ELECTRICAL

54A-158

REMOVAL SERVICE POINT

 <<A>> REAR FOG LAMP ASSEMBLY
REMOVAL

Push the rear fog lamp assembly to the right to bend
the hook, and then remove by disengaging the claw
from the rear bumper.

SIDE TURN-SIGNAL LAMP

REMOVAL AND INSTALLATION

M1541800200509

<DOOR MIRROR TYPE>

For the side turn-signal lamp removal and installation
procedures, refer to GROUP 51

− Door Mirror .

<FENDER PANEL TYPE>

ACB05650

AC506857

AB

1

Section A – A

Claw

A

A

1

Hook

Fender panel

Front of vehicle

Removal

,<<A>>

1.

Side turn-signal lamp assembly

REMOVAL SERVICE POINT

<<A>> SIDE TURN-SIGNAL LAMP
ASSEMBLY REMOVAL

Push the side turn-signal lamp assembly toward the
vehicle rear to bend the hook, and then remove by
disengaging the claw from the fender panel.

INTERIOR LAMP

CHASSIS ELECTRICAL

54A-159

INTERIOR LAMP

SPECIAL TOOLS

M1541301600345

Tool

Number

Name

Use

ACB05421

MB992745

MB992746

MB992744

MB992747

MB992748

a

b

c

d

e

DO NOT USE

AB

a. MB992744
b. MB992745
c. MB992746
d. MB992747
e. MB992748

a. Vehicle

communicatio
n
interface-Lite
(V.C.I.-Lite)

b. V.C.I.-Lite

main harness
A (for vehicles
with CAN
communicatio
n)

c. V.C.I.-Lite

main harness
B (for vehicles
without CAN
communicatio
n)

d. V.C.I.-Lite

USB cable
short

e. V.C.I.-Lite

USB cable
long

Diagnosis code, service data and
actuator test check.

MB991910

MB991826

MB991955

MB991911

MB991824

MB991827

MB991825

a

b

c

d

e

f

DO NOT USE

INTERIOR LAMP

CHASSIS ELECTRICAL

54A-160

MB991955

a. MB991824
b. MB991827
c. MB991910
d. MB991911
e. MB991825
f. MB991826

M.U.T.-III
sub-assembly

a. Vehicle

Communicati
on Interface
(V.C.I.)

b. M.U.T.-III

USB cable

c. M.U.T.-III

main harness
A (Vehicles
with CAN
communicatio
n system)

d. M.U.T.-III

main harness
B (Vehicles
without CAN
communicatio
n system)

e. M.U.T.-III

measure
adapter

f. M.U.T.-III

trigger
harness

CAUTION

For vehicles with CAN
communication, use M.U.T.-III
main harness A to send
simulated vehicle speed. If you
connect M.U.T.-III main harness B
instead, the CAN communication
does not function correctly.
Diagnosis code, service data and
actuator test check.

MB991223

a

d

c

b

DO NOT USE

BA

MB991223

a. MB991219
b. MB991220
c. MB991221
d. MB991222

Harness set

a. Check

harness

b. LED harness
c. LED harness

adapter

d. Probe

Continuity check and voltage
measurement at harness wire or
connector

a. For checking connector pin

contact pressure

b. For checking power supply

circuit

c. For checking power supply

circuit

d. For connecting a locally sourced

tester

Tool

Number

Name

Use
