FLOOR CONSOLE ASSEMBLY

INTERIOR

52A-8

REAR FLOOR CONSOLE ASSEMBLY

REMOVAL AND INSTALLATION

M1521005700664

ACC00514 AB

10

6

4

7

3

5

11

12

8

2

1

9

11 ± 2 N·m

11 ± 2 N·m

5.0 ± 1.0 N·m

NOTE

       :Clip positions

•

Heated switch connector
connection <Vehicles with heated
seat>

4.

Shift lever panel assembly

5.

Bezel

6.

4WD switch or S-AWC switch

7.

Plug

8.

Heated switch <Vehicles with
heated seat>

9.

Ring

10. Boot assembly

Removal steps (Continued)

•

Inside transmission antenna (front)
(Refer to GROUP 42B

− Outside

Transmission Antenna, Inside
Transmission Antenna Assembly,
Receiver Antenna Module ).

11. Floor console front
12. Floor console trim plate bracket
13. Floor console bracket centre

Removal steps (Continued)

Disassembly steps

1.

Floor rear console accessory panel

•

Accessory socket connector
connection

•

USB adapter connector connection

2.

Rear floor console assembly
mounting bolt

3.

Rear floor console assembly

4.

Floor console lid lock lever

5.

Armrest tray

6.

Floor console lid lock lever

7.

Floor console lid

8.

Floor console box inner

9.

USB adapter (Refer to GROUP
54A

− USB Adapter Removal and

Installation )

10. Accessory socket
11. Rear console
12. Floor console bracket rear

TRIMS

INTERIOR

52A-9

TRIMS

INTERIOR TRIM

REMOVAL AND INSTALLATION

M1521001102268

ACB05044 AB

10

6

7

3

2

11

5

17

18

15

1

13

12

14

19

9

N

8

4

13

16

1.

Front scuff plate

2.

Cowl side trim

3.

Rear scuff plate

4.

Rear scuff plate front

5.

Front door opening trim

6.

Rear door opening trim

7.

Front pillar trim

8.

Garnish clip <Vehicles with curtain
air bag>

9.

Centre pillar trim lower cover

•

Seat belt pre-tensioner connector
connection

10. Centre pillar trim, lower
11. Centre pillar trim, upper
12. Rear end trim

Quarter trim lower and quarter
trim upper removal steps

13. Cargo hook assembly
14. Jack lid assembly
15. Quarter trim lower
16. Quarter trim tray
17. Quarter trim cover
18. Quarter trim upper cap
19. Quarter trim upper

Disassembly steps (Continued)

TRIMS

INTERIOR

52A-10

NOTE: For the vehicles with curtain air bag, install
the front pillar trim and quarter trim upper provided
for curtain air bag.

CLIP AND CLAW POSITIONS

ACB05998

AB

B

Section A – A

Section F – F

Section J – J

Section K – K

Section L – L

Section M – M

Section G – G

Section H – H

Section I – I

Section B – B

Section C – C

Section E – E

Section D – D

7

B

C

C

7

D

1, 3

E

9

F

F

10

D

D

D

H

H

12

I

15

J

J

15

K

K

I

15

M

19

19

E

Clip

Clip

Clip

Clip

Clip

Clip

Claw

Claw

Claw

Bolt

A

A

2

Clip

M

G

G

10

Claw

Clip

L

L

NOTE: Each number in the illustration indicates a

part number.

TRIMS

INTERIOR

52A-11

DOOR TRIM

REMOVAL AND INSTALLATION

M1521006401528

ACB05047

Section A – A

Section B – B

1

AB

1

3

6

8

4

11

A

A

B

B

4

Clip

Clip

NOTE
       : Clip positions

9

7

5

10

2

Front door trim removal steps

•

Tweeter connector

1.

Front door sash trim

<<

A

>>

2.

Inside handle cover cap

<<

B

>>

3.

Door trim cap

<<

C

>>

>>

A

<<

4.

Front door trim

5.

Power window switch assembly

6.

Power window switch panel

•

Power window switch connector

7.

Power window switch

8.

Remote-controlled mirror switch

9.

Inside handle cover

10. Door beltline weatherstrip inner
11. Front door pull handle bracket

Front door trim removal steps
