ACTIVE STABILITY CONTROL SYSTEM (ASC) ACTIVE STABILITY CONTROL SYSTEM (ASC) 35C-8 CONSTRUCTION DIAGRAM SENSOR M2355001100471 WHEEL SPEED SENSOR Refer to GROUP 35B − Sensor P.35B-2 . G & YAW RATE SENSOR The G & yaw rate sensor is integrated in the STEERING WHEEL SENSOR The steering wheel sensor is attached to the column ASC OFF SWITCH The ASC OFF switch is installed on the side air outlet ASC OFF SWITCH OPERATION AND SYSTEM OPERATION NOTE: The stability control is available when the ACTUATOR M2355001200467 HYDRAULIC UNIT The hydraulic unit incorporates the ABS control and the ASC control. NOTE: For the internal hydraulic circuit of the P.35C-16 . ACB06006 AB ASC-ECU ACB04993AB Steering wheel sensor ACB04992AB ASC OFF switch ASC OFF switch operation TCL Stability HSA BA Brake control Engine control Not operated Enabled Enabled Enabled Enabled Enabled Operated (Press and hold for 3 Prohibited Prohibited Prohibited Enabled Enabled manuals search engine
|
