MAJOR SPECIFICATIONS

GENERAL

00-18

Item

GF6W

XJSXZL6/XJSXZR6

Vehicle
dimension mm

Front track

1

1,540

Overall width

2

1,800

Front overhang

3

955

Wheelbase

4

2,670

Rear overhang

5

1,030

Overall length

6

4,655

Ground clearance (unladen)

7

215

Overall height (unladen)

8

1,680

Rear track

9

1,540

Vehicle weight
kg

Kerb weight

Without full optional parts 1,555

With full optional parts

1,644

Gross vehicle weight

2,260

Gross axle weight rating-front

1,150

Gross axle weight rating-rear

1,250

Gross combination weight

4,360

Seating capacity

5

Engine

Model No.

4N14

Type

DOHC Direct
injection-diesel with
intercooled
turbocharger engine,
Auto Stop & Go

Total displacement mL

2,268

Max. output <EEC> kW/rpm

130/3,500

Max. torque <EEC> N

⋅m/rpm

380/2,000

Fuel system

Fuel supply system

Electrical fuel injection
(Direct injection-Diesel
engine control system)

Transmission

Model code

W6MBA

Type

Electronic control 4WD,
6M/T

Turning radius
m

Body

5.73

Wheel

5.3

Downloaded from

www.Manualslib.com



manuals search engine



MAJOR SPECIFICATIONS

GENERAL

00-19

VEHICLES FOR RUSSIA

<2000>

ACB04339AB

1
2

3

4

5

6

7

8

9

Item

GF2W

XTSHL6Z

XTSHZL6Z

Vehicle
dimension mm

Front track

1

1,540

1,540

Overall width

2

1,800

1,800

Front overhang

3

955

955

Wheelbase

4

2,670

2,670

Rear overhang

5

1,030

1,030

Overall length

6

4,655

4,655

Ground clearance (unladen)

7

215

215

Overall height (unladen)

8

1,680

1,680

Rear track

9

1,540

1,540

Vehicle weight
kg

Kerb weight

Without full optional parts 1,415

1,480

With full optional parts

1,484

1,559

Gross vehicle weight

1,985

1,985

Gross axle weight rating-front

1,150

1,150

Gross axle weight rating-rear

1,250

1,250

Gross combination weight

3,665

3,665

Seating capacity

5

5

Engine

Model No.

4B11

4B11

Type

DOHC MIVEC

DOHC MIVEC

Total displacement mL

1,998

1,998

Max. output <EEC> kW/rpm

107/6,000

107/6,000

Max. torque <EEC> N

⋅m/rpm

196/4,200

196/4,200

Fuel system

Fuel supply system

MPI

MPI

Transmission

Model code

F1CJA

W1CJA

Type

Front wheel drive 2WD,
INVECS-III CVT with
sport mode

Electronic control 4WD,
INVECS-III CVT with
sport mode

Turning radius
m

Body

5.73

5.73

Wheel

5.3

5.3

Downloaded from

www.Manualslib.com



manuals search engine



MAJOR SPECIFICATIONS

GENERAL

00-20

<2400>

Item

GF3W

XTHHZL6Z

Vehicle
dimension mm

Front track

1

1,540

Overall width

2

1,800

Front overhang

3

955

Wheelbase

4

2,670

Rear overhang

5

1,030

Overall length

6

4,655

Ground clearance (unladen)

7

215

Overall height (unladen)

8

1,680

Rear track

9

1,540

Vehicle weight
kg

Kerb weight

Without full optional parts 1,495

With full optional parts

1,569

Gross vehicle weight

2,210

Gross axle weight rating-front

1,150

Gross axle weight rating-rear

1,250

Gross combination weight

3,890

Seating capacity

5

Engine

Model No.

4B12

Type

DOHC MIVEC

Total displacement mL

2,360

Max. output <EEC> kW/rpm

123/6,000

Max. torque <EEC> N

⋅m/rpm

222/4,100

Fuel system

Fuel supply system

MPI

Transmission

Model code

W1CJA

Type

Electronic control 4WD,
INVECS-III CVT with
sport mode

Turning radius
m

Body

5.73

Wheel

5.3

Downloaded from

www.Manualslib.com



manuals search engine



11-1

GROUP 11

ENGINE

MECHANICAL

CONTENTS

GENERAL INFORMATION . . . . . . . .

11-2

BASE ENGINE . . . . . . . . . . . . . . . . . .

11-3
