WIPER AND WASHER EXTERIOR 51-13 Rain sensitive AUTO wiper function <Optional> • Lighting control sensor (rain sensor) has been installed in the upper part of the windshield to • The lighting control sensor detects the raindrops on the windshield surface using the optical ele- • The lighting control sensor detects the raindrops using the reflections of infrared rays, and • Dry windshield: All infrared rays emitted from the emitter diode are reflected by the windshield and • Wet windshield: Part of the infrared rays emitted from the emitter diode are transmitted to outside NOTE: Using the customise function, the rain sensi- Delayed finishing wipe function <Initial condition: with function> 1. When the washer lever of the column switch is operated for 0.5 seconds or longer with the igni- NOTE: Using the customise function, the delayed fin- ACB05683AB Windshield Lighting control sensor Windshield Receiver diode Emitter diode Raindrop High Receiver diode Emitter diode Reduced Windshield Optical Optical Dry windshield Wet windshield Infrared rays Infrared rays |
