SUNROOF ASSEMBLY

BODY

42-63

NOTE:

Prior to the wiring harness inspection, check the
junction block connectors C-203, C-210 and the
intermediate connectors C-116, C-218 and repair if
necessary. <L.H. drive vehicles>

AC301396

Connector: C-116 <L.H. drive vehicles>

AO

9

21

33

35

24

12

3 4

7

8

5 6

39

28

41

30

18

4243

31

1920

32

40

29

1617

38

27

15

37

36

26

14

13

25

2

1

34

23

11

10

22

AC210475

Connector: C-203, C-210
<L.H. drive vehicles>

C-210

BB

C-203

Junction Block (Front View)

C-203

C-210

AC210476

Junction block (Rear view)

AG

5

4

3

2

1

Connector: C-218 <L.H. drive vehicles>

SUNROOF ASSEMBLY

BODY

42-64

NOTE:

Prior to the wiring harness inspection, check the
junction block connectors C-203, C-210 and the
intermediate connectors A-14, C-124, C-218 and
repair if necessary. <R.H. drive vehicles>

•

Check the power supply line for open circuit.

Q: Is the check result normal?

YES :

The trouble can be an intermittent

malfunction (Refer to GROUP 00

−

 How to

Cope with Intermittent Malfunction

P.00-6

).

NO :

Repair the wiring harness.

AC309231AB

A-14(GR)

Connector: A-14 <R.H. drive vehicles>

AC309232

AB

Connector: C-124 <R.H. drive vehicles>

AC309233

Connector: C-203, C-210
<R.H. drive vehicles>

C-210

AB

Junction Block (Front View)

C-203

C-203

C-210

AC309230

Junction block (Rear view)

AB

5

4

3

2

1

Connector: C-218 <R.H. drive vehicles>

SUNROOF ASSEMBLY

BODY

42-65

STEP 8. Measure the resistance at the D-09
sunroof motor assembly connector.

(1) Disconnect the sunroof motor assembly

connector, and measure at the harness side.

(2) Check the resistance between the sunroof motor

assembly connector and body earth.

•

Resistance between D-09 sunroof motor
assembly connector terminal No.5 and body
earth.

OK: 2

Ω

 or less

Q: Is the check result normal?

YES :

Go to Step 10.

NO :

Go to Step 9.

STEP 9. Check the wiring harness between D-09
sunroof motor assembly connector terminal No.5
and body earth.

NOTE:

Prior to the wiring harness inspection, check
intermediate connector C-218, and repair if
necessary.

•

Check earth line for open circuit.

AC301408

Harness side

AK

9

10

4 3

6

8 7

2

5

1

Connector: D-09
<L.H. drive vehicles>

AC309220

AC

Connector: D-09
<R.H. drive vehicles>

Harness side

9

10

4 3

6

8 7

2

5

1

9

10

4 3

6

8 7

2

5

1

AC301724

Connector D-09
(Harness side)

AB

AC301408

Harness side

AK

9

10

4 3

6

8 7

2

5

1

Connector: D-09
<L.H. drive vehicles>

AC309220

AC

Connector: D-09
<R.H. drive vehicles>

Harness side

9

10

4 3

6

8 7

2

5

1

AC210476

Junction block (Rear view)

AG

5

4

3

2

1

Connector: C-218 <L.H. drive vehicles>

AC309230

Junction block (Rear view)

AB

5

4

3

2

1

Connector: C-218 <R.H. drive vehicles>

SUNROOF ASSEMBLY

BODY

42-66

Q: Is the check result normal?

YES :

The trouble can be an intermittent

malfunction (Refer to GROUP 00

−

 How to

Cope with Intermittent Malfunction

P.00-6

).

NO :

Repair the wiring harness.

STEP 10. Retest the system.

The sunroof assembly should now work normally.

Q: Is the check result normal?

YES :

The trouble can be an intermittent

malfunction (Refer to GROUP 00

−

 How to

Cope with Intermittent Malfunction

P.00-6

).

NO :

Replace the sunroof motor assembly.

INSPECTION PROCEDURE 2: Any of the sunroof switch positions is defective.

CAUTION

Whenever the ECU is replaced, ensure that the
input and output signal circuits are normal.

COMMENTS ON TROUBLE SYMPTOM
If any of the sunroof switch positions is defective, the
communication line between the sunroof switch and
the sunroof motor assembly (sunroof-ECU) may be
defective.

Possible causes

•

Malfunction of the sunroof switch

•

Malfunction of the sunroof motor assembly
(sunroof-ECU)

•

Damaged harness wires and connectors

Wire colour code
B : Black     LG : Light green     G : Green     L : Blue     W : White     Y : Yellow     SB : Sky blue
BR : Brown     O : Orange     GR : Gray     R : Red     P : Pink     V : Violet

CONTROL CIRCUIT

SUNROOF
SWITCH

SUNROOF
MOTOR ASSEMBLY

Sunroof Switch Circuit
