HOOD

TSB Revision

BODY

42-7

HOOD

REMOVAL AND INSTALLATION

M1421001600185

AC003758

ADJUSTMENT OF CLEARANCE AND HIGHT
AROUND HOOD

9 N·m
80 in-lb

4

6

5

8

7

11

9

10

1

3

2

12

13

14

9 N·m
80 in-lb

12 N·m
106 in-lb

22 N·m
16 in-lb

12 N·m
106 in-lb

12

11

3

12

1

ADJUSTMENT OF HOOD STEP AND
HOOD STRIKER LINKAGE

AB

1. HOOD LOCK RELEASE HANDLE
2. HOOD BUMPER
3. HOOD BUMPER
4. HOOD DAMPER
5. HOOD SIDE WEATHERSTRIP
6. HOOD WEATHERSTRIP
7. FRONT HOOD WEATHERSTRIP
8. HOOD SUPPORT ROD
9. HOOD SWITCH <VEHICLES WITH

THEFT-ALARM SYSTEM>
HOOD AND HOOD HINGE
REMOVAL STEPS

• WASHER HOSE CONNECTION

10. HOOD

• FRONT DECK GARNISH (REFER

TO GROUP 51, WINDSHIELD
WIPER AND WASHER

P.51-16

.)

11. HOOD HINGE

HOOD LATCH AND HOOD LOCK
RELEASE CABLE REMOVAL
STEPS

• RADIATOR GRILL

12. HOOD LATCH
13. CABLE PROTECTOR
• JUNCTION BLOCK

14. HOOD LOCK RELEASE CABLE

HOOD AND HOOD HINGE
REMOVAL STEPS (Continued)

HOOD

TSB Revision

BODY

42-8

INSPECTION

M1421001700171

HOOD SWITCH CONTINUITY CHECK <VEHICLES
WITH THEFT-ALARM SYSTEM>

SWITCH
POSITION

TESTER
CONNECTION

SPECIFIED
CONDITION

Hood switch
unpressed

1

− 2

Less than 2 ohms

Hood switch
depressed

1

− 2

Open circuit

AC003759

1

2

VIEW A

A

AB

FENDER

TSB Revision

BODY

42-9

FENDER

REMOVAL AND INSTALLATION

M1421001900368

Pre-removal and Post-installation Operation
• Front Bumper Removal and Installation (Refer to GROUP

51, Front Bumper

P.51-2

.)

• Front Deck Garnish Removal and Installation (Refer to

GROUP 51, Windshield Wiper and Washer

P.51-16

.)

• Headlight Removal and Installation (Refer to GROUP 54,

Lighting System

P.54-152

.)

• Wide Fender Removal and Installation (Refer to GROUP

51, Wide Fender

P.51-10

.)

AC308659

AD

1

2

3

REMOVAL STEPS
1. MUD GUARD
2. SPLASH SHIELD
3. FENDER

FUEL FILLER LID

TSB Revision

BODY

42-10

FUEL FILLER LID

REMOVAL AND INSTALLATION

M1421002500192

Pre-removal and Post-installation Operation
• Driver's Seat and Rear Seat Removal and Installation

(Refer to GROUP 52A, Front Seat

P.52A-44

 and Rear

Seat

P.52A-49

.)

• Quarter Trim Lower Removal and Installation (Refer to

GROUP 52A, Trims

P.52A-41

.)

AC003761

1

2

3

4

1

2

FUEL FILLER DOOR HEIGHT AND
CLEARANCE ADJUSTMENT

AB

REMOVAL STEPS
1. FUEL FILLER DOOR PANEL

ASSEMBLY

2. FUEL FILLER DOOR HOOK

ASSEMBLY

3. LID LOCK RELEASE HANDLE
4. FUEL FILLER DOOR LOCK

RELEASE CABLE

REMOVAL STEPS (Continued)
