ON-VEHICLE SERVICE
TSB Revision
AUTOMATIC TRANSMISSION
23Aa-11
ON-VEHICLE SERVICE
AUTOMATIC TRANSMISSION CONTROL COMPONENT LAYOUT
M1231102000135
MB995062
Flushing tool
MLR-6906C or
equivalent
Flushing cooler and tube
MD998727 Oil pan
remover
MD998727-01
Removal of oil pan
MB990784
Ornament remover
General service
tool
Removal of shift knob
TOOL
TOOL NUMBER AND
NAME
SUPERSESSION
APPLICATION
D998727
MB990784
NAME
SYMBOL NAME
SYMBOL
2WD detection switch
K
Input shaft speed sensor
E
2WD/4WD detection switch
K
Output shaft speed sensor
L
4H detection switch
K
Powertrain control module (PCM)
P
4LLc detection switch
K
Rear propeller shaft speed sensor
J
Accelerator pedal position sensor
U
Select switch
S
ASC-ECU
N
Shift actuator
H
A/T control relay
O
Shift switch (Up and down)
S
A/T control solenoid valves
M
Solenoid valves A and B
C
Center differential lock detection switch
K
Stoplight switch
V
Crankshaft position sensor
B
Transfer-ECU
R
Data link connector
T
Transfer shift lever switch
Q
Dual pressure switch
A
Transmission fluid temperature sensor
M
Freewheel engage switch
D
Transmission range switch
F
Front propeller shaft speed sensor
G
Vehicle speed sensor
I
