CONDENSER AND CONDENSER FAN MOTOR

TSB Revision

HEATER, AIR CONDITIONING AND VENTILATION

55A-151

INSPECTION

M1552006800121

MOTOR ASSEMBLY CHECK

BATTERY (+)
CONNECTION
TERMINAL

BATTERY (

−)

CONNECTION
TERMINAL

MOTOR OPERATION

1

2

Rotates

ACX00845 AB

REFRIGERANT LINE

TSB Revision

HEATER, AIR CONDITIONING AND VENTILATION

55A-152

REFRIGERANT LINE

REMOVAL AND INSTALLATION

M1552006400286

<Vehicles without rear cooler or rear A/C>

Pre-removal and Post-installation Operation
• Refrigerant Discharging and Charging (Refer to

P.55A-

119

.)

• Condense Tank Removal and Installation (Refer to

GROUP 14, Radiator

P.14-8

.)

• Engine Cover Removal and Installation.

• Battery and Battery Tray Removal and Installation.

1

2

3

4

5

9.8 – 2 N•m
87 – 17 in-lb

9.8 – 2 N•m
87 – 17 in-lb

9.8 – 2 N•m
87 – 17 in-lb

Low pressure-side service valve

High pressure-side
service valve

6

N

6

N

6

N

6

N

6

N

PIPE CONNECTIONS

O-RING

O-RING

A/C COMPRESSOR OIL:
DENSO OIL 8

1, 2, 3, 4, 5

4

AC205154AB

REMOVAL STEPS

1.

DUAL PRESSURE SWITCH

<<A>>

2.

DISCHARGE HOSE

<<A>>

3.

SUCTION HOSE

<<A>>

4.

LIQUID PIPE A

<<A>>

5.

LIQUID PIPE B

6.

O-RING

REMOVAL STEPS (Continued)

REFRIGERANT LINE

TSB Revision

HEATER, AIR CONDITIONING AND VENTILATION

55A-153

<Vehicles with rear cooler or rear A/C>

AC001705AC

PIPE CONNECTIONS

O-RING

O-RING

A/C COMPRESSOR OIL:
DENSO OIL 8

1, 2, 3, 4

3, 4, 5, 6, 7,
8, 9, 10, 11

9.8 ± 2.0 N·m
87 ± 18 in-lb

9.8 ± 2.0 N·m
87 ± 18 in-lb

9.8 ± 2.0 N·m
87 ± 18 in-lb

9.8 ± 2.0 N·m
87 ± 18 in-lb

14 ± 0.5 N·m
124 ± 4 in-lb

33 ± 1.0 N·m
24 ± 1 in-lb

14 ± 0.5 N·m
124 ± 4 in-lb

14 ± 0.5 N·m
124 ± 4 in-lb

33 ± 1.0 N·m
24 ± 1 ft-lb

33 ± 1.0 N·m
24 ± 1 ft-lb

33 ± 1.0 N·m
24 ± 1 ft-lb

1

2

3

11

6

5

4

7

8

10

9

High pressure-side service valve

Low pressure-side service valve

14 ± 0.5 N·m
124 ± 4 in-lb

14 ± 0.5 N·m
124 ± 4 in-lb

N

12

N

12

N

12

12

N

12

N

12

N

12

N

12

N

12

N

REMOVAL STEPS

1.

DUAL PRESSURE SWITCH

<<A>>

2.

DISCHARGE FLEXIBLE HOSE

<<A>>

3.

SUCTION FLEXIBLE HOSE

<<A>>

4.

LIQUID PIPE A

<<A>>

5.

SUCTION PIPE A

<<A>>

6.

LIQUID PIPE B

<<A>>

7.

SUCTION PIPE B

<<A>>

8.

LIQUID PIPE C

<<A>>

9.

SUCTION PIPE C

<<A>>

10. LIQUID PIPE D

<<A>>

11. LIQUID PIPE E
12. O-RING

REMOVAL STEPS (Continued)

REFRIGERANT LINE

TSB Revision

HEATER, AIR CONDITIONING AND VENTILATION

55A-154

REMOVAL SERVICE POINT

.

<<A>> HOSE AND PIPE REMOVAL

CAUTION

Seal the hoses completely, otherwise the compressor oil
and receiver will absorb water vapor easily, possibly dam-
aging the compressor and deteriorating performance.
Plug the disconnected hose, pipe, condenser, compressor and
heater unit nipple to prevent foreign matter from getting into
them.
