AUTOMATIC TRANSAXLE DIAGNOSIS TSB Revision AUTOMATIC TRANSAXLE 23A-207 STEP 8. Measure the supply voltage at A/T control (1) Disconnect solenoid valve assembly harness connector B-108. (2) Turn the ignition switch to the "ON" position. (3) Measure the voltage between harness connector B-108 terminal 9 and ground. • The voltage should equal battery positive voltage. (4) Turn the ignition switch to the "LOCK" (OFF) position. YES : Go to Step 11. STEP 9. Check A/T control relay connector B-16X in the Q: Are the connectors and terminals in good condition? YES : Go to Step 10. GROUP 00E, Harness Connector Inspection AC306322 CONNECTOR: B-108 B-108 (GR) AC TRANSMISSION 2 7 1 8 3 9 4 6 10 5 AC210680 2 5 6 10 4 9 3 8 1 7 AB B-108 HARNESS AC306354 RELAY BOX AB CONNECTOR: B-16X 2 1 3 4 FRONT OF AC306322 CONNECTOR: B-108 B-108 (GR) AC TRANSMISSION 2 7 1 8 3 9 4 6 10 5 |
