AUTOMATIC TRANSAXLE DIAGNOSIS TSB Revision AUTOMATIC TRANSAXLE 23A-83 STEP 11. Measure the ground circuit for resistance at the (1) Disconnect connector B-109 from the speed sensor and measure at the harness side. (2) Measure the resistance between terminal 1 and ground. • The resistance should measure less than 2 ohms. Q: Is the measured resistance less than 2 ohms? YES : Go to Step 16. AC305354 TRANSMISSION B-109 (GR) AC CONNECTOR: B-109 1 3 2 3 1 2 AC210632 B-109 HARNESS AD |
