MULTIPORT FUEL INJECTION (MFI) DIAGNOSIS TSB Revision MULTIPORT FUEL INJECTION (MFI) <3.8L ENGINE> 13B-149 STEP 3. Measure the sensor supply voltage at engine harness side. (2) Turn the ignition switch to the "ON" position. (3) Measure the voltage between terminal No. 1 and ground. • Voltage should be between 4.5 and 4.9 volts. (4) Turn the ignition switch to the "LOCK" (OFF) position. YES : Go to Step 7. 1 2 AK303037 HARNESS CONNECTOR: B-104 AB B-104 (B) THROTTLE AK303039 AB 2 1 B-104 HARNESS |
