HOW TO READ SPLICE LOCATIONS

TSB Revision

SPLICE LOCATIONS

80B-3

HOW TO READ SPLICE LOCATIONS

M1802000100409

"Splice locations" describes splice points of each wiring harness on an actual vehicle. Some variations are
included in one splice location. Accordingly, some locations may not be applicable for individual vehicles.

AC002683

Indicates a splice point number.
The splice point numbers are identical to those in "CIRCUIT DIAGRAMS," making them easy to use.
In addition, the splice point numbers are usually numbered clockwise.

Example: S 013

Sequential number

Prefix meaning splice point

S013
S014

S015

S016

S033

S032

S031

INDEX

TSB Revision

SPLICE LOCATIONS

80B-4

INDEX

M1802000900676

The reference page numbers always indicate the first page of each sub-section. Therefore, the splice location
numbers referenced may not be shown on that page.

SPLICE
LOCATION
NO.

PAGE

SPLICE
LOCATION
NO.

PAGE

SPLICE
LOCATION
NO.

PAGE

SPLICE
LOCATION
NO.

PAGE

S001

P.80B-5

S029

P.80B-6

S057
