MULTIPORT FUEL INJECTION(MFI) DIAGNOSIS TSB Revision MULTIPORT FUEL INJECTION (MFI) <3.0L> 13B-33 STEP 1. Using scan tool MB991502, check data list item 12: CAUTION To prevent damage to scan tool MB991502, always turn the 12, Volume Air Flow Sensor. (4) Warm up the engine to normal operating temperature:80 ° C to 96 ° C(176 ° F to 205 ° F). • The standard value during idling should be 10Hz or • When the engine is revved, the frequency should (5) Turn the ignition switch to the "LOCK"(OFF) position. Q: Is the sensor operating properly? YES : It can be assumed that this malfunction is intermittent. Refer to GROUP 00, How to Use Troubleshooting/ ). NO : Go to Step 2. STEP 2. Replace the volume air flow sensor. , Procedure 6 − Other Monitor. (3) Check the diagnostic trouble code (DTC). Q: Is the DTC P0102 is output? YES : Replace the PCM. Then go to Step 3. STEP 3. Test the OBD-II drive cycle. , Procedure 6 − Other Monitor. (2) Check the diagnostic trouble code (DTC). Q: Is the DTC P0102 is output? YES : Retry the troubleshooting. AC003081 AB 16 PIN MB991502 ACX02480 CONNECTOR : B-14 AC VOLUME AIR |
