MULTIPORT FUEL INJECTION (MFI) DIAGNOSIS TSB Revision MULTIPORT FUEL INJECTION (MFI) <3.8L ENGINE> 13B-768 STEP 9. Measure the 5-volt reference signal at fuel tank 52A, Rear Seat (2) Remove the hole cover (RH). (3) Disconnect fuel tank differential pressure sensor connector D-23. (4) Use special tool MB991658 to connect terminals 1,2 and 3 of the fuel tank differential pressure sensor connector D-23. (5) Turn the ignition switch to the "ON" position. • The voltage should measure between 4.9 and 5.1 volts. (7) Turn the ignition switch to the "LOCK" (OFF) position. YES : Go to Step 12. AC306089 HOLE COVER AB AC305266 CONNECTOR: D-23 AB D-23 (B) AC306775 AB MB991658 1 2 3 D-23 (B)
|
