SYMPTOM PROCEDURES TSB Revision SIMPLIFIED WIRING SYSTEM (SWS) 54B-340 . TECHNICAL DESCRIPTION (COMMENT) If one of the headlights does not illuminate, a head- . TROUBLESHOOTING HINTS • The headlight bulb may be defective • The wiring harness or connectors may have loose, corroded, or damaged terminals, or termi- . DIAGNOSIS Required Special Tool: • MB991223: Harness Set STEP 1. Check the headlight operation. LH (low and high beam) : Go to Step 2. Procedure H-2 "The headlights (low-beam) do not High beam only (both RH and LH) : Refer to Inspection Procedure H-3 "The headlights (high-beam) do not High beam indicator light : Refer to Inspection Procedure H-8 "The high-beam indicator light does not illuminate STEP 2. Check headlight (LH) connector A-19 for loose, YES : Go to Step 3. to GROUP 00E, Harness Connector Inspection . Check that the headlights illuminate normally. STEP 3. Check headlight (LH) bulb. out. Q: Is headlight (LH) bulb normal? YES : Go to Step 4. headlights illuminate normally. AC400526 AJ CONNECTOR: A-19 A-19 (GR) HARNESS SIDE |
