SYMPTOM PROCEDURES TSB Revision SIMPLIFIED WIRING SYSTEM (SWS) 54B-324 STEP 16. Check the wiring harness between rear (RH) connector F-03 (terminal 2) and ground in good that the taillight (RH) illuminates normally. NO : The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged STEP 17. Check joint connector C-01 for loose, corroded YES : Go to Step 18. to GROUP 00E, Harness Connector Inspection . Check that the taillight (RH) illuminates normally. AC305260 AH CONNECTOR: F-03 HARNESS SIDE AC305231 CONNECTOR: C-01 BO |
