SERVICE BULLETIN

QUALITY INFORMATION ANALYSIS

OVERSEAS SERVICE DEPT. MITSUBISHI MOTORS CORPORATION

SERVICE BULLETIN

No.: MSB-01E55-502

Date

2001-09-20

<Model>

<M/Y>

Subject:

AIR CONDITIONING REFRIGERANT
PROCEDURE

Group:

HEATER, A/C &
VENTILATION

Draft No.: 00AL112911

CORRECTION

INTERNATIONAL
CAR
ADMINISTRATION
OFFICE

T.MASAKI-MANAGER
TECHNICAL SERVICE PLANNING

(EC)PAJERO PININ
(H60,H70)
(EC)PAJERO (V60,70)
(EC)SPACE
RUNNER/SPACE
WAGON(N60,80,90)
(EC)COLT/LANCER
(CK01,CJ0A)
(EC)L200(K00T,K30T)
(EC)L300(P00)
(EC)L400(PA0-PD0)
(EC)PAJERO SPORT
(K80W,K90W)
(EC)SPACE STAR
(EC)CARISMA
(EC)GALANT(EA0A)

00-10

01-10
99-10

93-10

97-10
95-10
95-10
99-10

97-10

1. Description:

The air conditioning refrigerant discharging procedure has been changed as described below.

2. Applicable Manuals:

Manual

Pub. No.

Language

Page(s)

’00 PAJERO PININ/MONTERO iO

CKRE00E1

(English) 55-13

Workshop Manual

CKRS00E1

(Spanish)

CKRF00E1

(French)

CKRG00E1

(German)

CKRD00E1

(Dutch)

’99 SPACE RUNNER/SPACE WAGON

PWDE9803

(English) 55-13

Workshop Manual

PWDS9804

(Spanish)

PWDF9805

(French)

PWDG9806

(German)

PWDD9807

(Dutch)

PWDW9808

(Swedish)

’96 COLT/LANCER

PWME9511

(English) 55-13

Workshop Manual

PWMS9512

(Spanish)

PWMF9513

(French)

PWMG9514

(German)

PWMD9515

(Dutch)

PWMW9516

(Swedish)

Manual

Pub. No.

Language

Page(s)

’99 SPACE STAR

CMXE99E1

(English) 55-13

Workshop Manual

CMXS99E1

(Spanish)

CMXF99E1

(French)

CMXG99E1

(German)

CMXD99E1

(Dutch)

CMXW99E1

(Swedish)

CMXI99E1

(Italian)

’97 L200

PWTE96E1

(English) 55-12

Workshop Manual

PWTS96E1

(Spanish)

PWTF96E1

(French)

PWTG96E1

(German)

’99 PAJERO SPORT/MONTERO SPORT

PWJE9812

(English) 55-14

Workshop Manual

PWJS9813

(Spanish)

PWJF9814

(French)

PWJG9815

(German)

’96 CARISMA

PWDE9502

(English) 55-12

Workshop Manual

PWDS9503

(Spanish)

PWDF9504

(French)

PWDG9505

(German)

PWDD9506

(Dutch)

PWDW9507

(Swedish)

’95 L400

PWWE9410

(English) 55-20

Workshop Manual

PWWS9411

(Spanish)

PWWF9412

(French)

PWWG9413

(German)

PWWD9414

(Dutch)

PWWW9415

(Swedish)

’97 GALANT

PWDE9611

(English) 55-13

Workshop Manual

PWDS9612

(Spanish)

PWDF9613

(French)

PWDG9614

(German)

PWDD9615

(Dutch)

PWDW9616

(Swedish)

’93 COLT/LANCER

PWME9117-D

(English) 55-18-4

PWMS9118-D

(Spanish)

PWMF9119-D

(French)

PWMG9120-D

(German)

PWMD9121-D

(Dutch)

PWMW9122-D

(Swedish)

Manual

Pub. No.

Language

Page(s)

’01 PAJERO/MONTERO

PWJE00001

(English) 55A-14

Workshop Manual VOL.2

PWJS00002

(Spanish)

’95 L300
Workshop Manual

PWWE9409

(English) 55-67-4

CD-ROM

Manual

Pub. No.

Language

Page(s)

1992-1995 COLT/LANCER

PWMM0009R

(English) 55-18-4

Workshop Manual

PWMM0009R

(French)

PWMM0009R

(German)

PWMM0009R

(Dutch)

1996-2001 COLT/LANCER

PWMH0018R

(English) 55-13

Workshop Manual

PWMH0018R

(Spanish)

PWMH0018R

(Swedish)

PWMK0019R

(French)

PWMK0019R

(German)

PWMK0019R

(Dutch)

2001 PAJERO/MONTERO

PWJT0008R

(English) 55A-14

Workshop Manual

PWJT0008R

(Spanish)

PWJT0008R

(French)

PWJT0008R

(German)

1999 SPACE RUNNER/SPACE WAGON

PWDH1816R

(English) 55-13

Workshop Manual

PWDH1816R

(Spanish)

PWDH1816R

(Swedish)

PWDK9817R

(French)

PWDK9817R

(German)

PWDK9817R

(Dutch)

2000 PAJERO PININ/MONTERO iO

CKRX00E1CD

(English) 55-13

Workshop Manual

CKRX00E1CD

(Spanish)

CKRZ00E1CD

(French)

CKRZ00E1CD

(German)

CKRZ00E1CD

(Dutch)

CKRZ00E1CD

(Italian)

1999 PAJERO SPORT/MONTERO SPORT PWJT9818R

(English) 55-14

Workshop Manual

PWJT9818R

(Spanish)

PWJT9818R

(French)

PWJT9818R

(German)

1999 SPACE STAR

CMXX99E1CD

(English) 55-13

Workshop Manual

CMXX99E1CD

(Spanish)

CMXX99E1CD

(Swedish)

CMXZ99E1CD

(French)

CMXZ99E1CD

(German)

CMXZ99E1CD

(Dutch)

CMXZ99E1CD

(Italian)

3. Details:

8. Start

the

engine.

9. Operate the air conditioner and set at the lowest temperature

(MAX. COOL).

10. Fix the engine speed at 1,500 r/min.
11. Tighten the handle of the adaptor valve (valve open), and

replenish refrigerant while checking the quantity through the
sight glass.

Caution
If the service can is inverted, liquid refrigerant may be
draw into the compressor damaging it by liquid
compression. Keep the service can upright to ensure the
refrigerant is changed in gas state.

12. After replenishing is completed, turn the handle of the adaptor

valve all the way back (valve close), and remove the quick joint.

NOTE
When there is remainder of refrigerant in the service can,
keep it for next use with the charge value and the valve of the
adaptor valve being closed.

DISCHARGING SYSTEM
1. Run the engine at an engine speed of 1,200-1,500 r/min for

approximately 5 minutes with the A/C operating to return to the
oil.

NOTE
Returning the oil will be more effective if it is done while
driving.

2. Stop the engine
3. Connect the charging hose (blue) to the adaptor valve with its

handle turned back all the way (valve closed).

4. Connect the quick joint to the charging hose (blue).
5. Install the quick joint to the low-pressure service valve.

NOTE
The low-pressure service valve should be connected to the
suction hose.

Caution
To connect the quick joint, press section “A” firmly against
the service valve until a click is heard. When connecting,
run your hand along the horse while pressing to ensure
that there are no bends in the hose.

6. Place the adaptor valve inside the container and discharge the

refrigerant by opening the handle gradually so that oil does not
gush out.

NOTE
Any oil remaining in the container should be returned to the
A/C system.

HEATER, AIR CONDITIONER AND VENTILATION – On-vehicle Service

DISCHARGING SYSTEM
Use the refrigerant recovery unit to discharge refrigerant gas from the system.

NOTE
Refer to the Refrigerant Recovery and Recycling Unit Instruction Manual for
operation of the unit.

<Correct>

Charging valve

Service can
(Refrigerant
container)

Low-pressure

service valve

A20X0108
