ENGINE LUBRICATION –

On-vehicle Service

12-6

4.

Install the oil pressure gauge.

NOTE
Use a adapter of PT 1/8 thread.

5.

Run the engine to warm it.

6.

After the engine has been warmed up, check that oil
pressure is within the standard value.

Standard value:

At idle: 29 kPa or more

At 3,500 r/min: 294 – 686 kPa

7.

Remove the oil pressure gauge.

8.

Apply the specified sealant to the thread of oil pressure
switch.

Specified sealant: 3M ATD Part No. 8660 or equivalent

9.

Use the special tool to tighten the oil pressure switch
to the specified torque.

Tightening torque: 19 Nm

Caution
Do not start the engine within one hour after the oil
pressure switch has been installed.

10. Install the oil pressure switch terminal.

MD998054

ENGINE LUBRICATION –

General/On-vehicle Service

12-1

GROUP 12

ENGINE LUBRICATION

GENERAL

OUTLINE OF CHANGE

A quality of the engine oil has been changed.

ON-VEHICLE SERVICE

Specified Engine Oil (ACEA and API classification):

 ACEA A1, A2, A3/API SG or higher

NOTES

GASOLINE DIRECT

INJECTION  (GDI)
