TYPE B (ACTUAL-MEASUREMENT DIMENSIONS)

BODY DIMENSIONS

2-12

FRONT BODY <SEDAN>

M4020006000131

AB300750AB

mm

18

24

25

26

17

23

19

20

21

22

Body centre point

Body centre point

1,502

576

813

951

734

540

730

318

870

873

758

872

600

894

1,091

1,390

1,340

1,437

1,040

1,508

AB300751AB

30

29

28

27

Body centre point

704

700

894

775

889

542

328

1,050

No. Standard measurement point

Hole shape Size mm

17

Centre of front bumper  mounting hole

Round

6.6

18

Centre of front end upper bar  water draining hole (Body centre point)

Round

8

19

Centre of harness mounting hole

Oblong

7

× 12

20

Centre of intercooler pipe mounting hole

Round

9

21

Centre of front fender mounting hole

Round

6.6

22

Centre of front strut mounting hole

Round

11.5

23

Front deck notch (Body centre point)

−

−

24

Centre of front fender mounting hole

Round

6.6

25

Centre of hood hinge mounting hole

Round

9

26

Corner of roof panel

−

−

27

Centre of front end crossmember outer positioning hole

Round

20

28

Centre of front bumper beam mounting hole

Round

10

29

Centre of headlamp mounting hole

Round

6.6

30

Centre of front end upper bar positioning hole (Body centre point)

Round

8

AB300752 AB

17

29

17,29

AB300753 AB

30

18

18,30

AB200346 AC

19

AB200347AC

20

AB200348AC

21

AB201830 AD

22

AB200350AC

23

AB200351AC

24,25

24

25

AB201833AD

26

TYPE B (ACTUAL-MEASUREMENT DIMENSIONS)

BODY DIMENSIONS

2-13

TYPE B (ACTUAL-MEASUREMENT DIMENSIONS)

BODY DIMENSIONS

2-14

SIDE BODY <SEDAN>

M4020007000134

AB300623

AB

31

32

33

34

35

36

37

38

39

40

mm

688

808

716

863

581

828

875

960

902

463

1,084

1,174

1,127

AB300622AB

42

41

33

37

45

43

44

731

1,124

1,041

1,067

1,094

1,100

355

338

837

901

No. Standard measurement point

Hole shape Size mm

31

Front pillar positioning notch (upper)

−

−

32

Front pillar positioning notch (lower)

−

−

33

Side roof rail positioning notch (front)

−

−

34

Side sill positioning notch (front)

−

−

35

Centre pillar positioning notch (upper)

−

−

36

Centre pillar positioning notch (lower)

−

−

37

Side roof rail positioning notch (rear)

−

−

38

Side sill positioning notch (rear)

−

−

TYPE B (ACTUAL-MEASUREMENT DIMENSIONS)

BODY DIMENSIONS

2-15

39

Quarter panel positioning notch (upper)

−

−

40

Quarter panel positioning notch (lower)

−

−

41

Centre of front door hinge mounting hole (upper)

Round

11

42

Centre of front door hinge mounting hole (lower)

Round

11

43

Centre of rear door hinge mounting hole (upper)

Round

11

44

Centre of rear door hinge mounting hole (lower)

Round

11

45

Centre of rear door switch mounting hole

Round

5

AB201836AD

32

42

32,42

AB202191AD

36

44

36,44

AB201838

AD

40

45

40,45

No. Standard measurement point

Hole shape Size mm
