DOOR AJAR WARNING TONE ALARM

TSB Revision

CIRCUIT DIAGRAMS

90-341

TRUNK LID
LATCH

REAR DOOR
SWITCH (RH)

FRONT DOOR
SWITCH (RH)

REAR DOOR
SWITCH (LH)

FRONT DOOR
SWITCH (LH)

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER

DOOR AJAR WARNING TONE ALARM

TSB Revision

CIRCUIT DIAGRAMS

90-342

DOOR AJAR WARNING TONE ALARM (CONTINUED)

INTERFACE
CIRCUIT

JOINT
CONNECTOR
(CAN2)

JOINT
CONNECTOR
(CAN3)

CAN DRIVE
CIRCUIT

ANALOG
INTERFACE
CIRCUIT

ANALOG
INTERFACE
CIRCUIT

FRONT SIDE

INPUT SIGNAL

·FRONT WHEEL
 SPEED SENSOR
·REAR WHEEL
 SPEED SENSOR

ASC-ECU

DOOR AJAR WARNING TONE ALARM

TSB Revision

CIRCUIT DIAGRAMS

90-343

ETACS-
ECU

INTERFACE
CIRCUIT

CAN DRIVE
CIRCUIT

DATA LINK
CONNECTOR

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER

(FUSE     )

5

ETACS-ECU

PARKING BRAKE REMINDER TONE ALARM

TSB Revision

CIRCUIT DIAGRAMS

90-344

PARKING BRAKE REMINDER TONE ALARM

M1901033500146

ETACS-
ECU

FUSIBLE
LINK

34

IGNITION
SWITCH (IG1)

IG1
RELAY

INTERFACE
CIRCUIT

LED DRIVE
CIRCUIT

CAN
TRANSCEIVER
CIRCUIT

CPU

COMBINATION
METER

CAN DRIVE
CIRCUIT

INTERFACE
CIRCUIT

JOINT
CONNECTOR
(CAN1)

TONE ALARM

FRONT SIDE

HEATED
SEAT
