REFERENCE MATERIALS – 4-ASPECT DIAGRAM
8-2
Auxiliary brake
light
Rear reflector
Tail light
Brake light
and Tail light
Rear direction
indicator and emer-
gency flashing display
Reversing light
Registration
plate light
1515 (track : 17-inch)
1500 (track: 15-inch)
Units: mm
Dipped headlight
Road light
Front direction
indicator and
emergency
flashing display
Front fog light
1515 (track: 17-inch)
1500 (track: (15-inch)
1700 (Overall width)
Side direction indicator
and emergency
flashing display
1880 (Interior length)
2625 (Wheelbase)
4490 (Overall length)
Schedule of Lighting Devices
The Schedule of Lighting Devices is included in the application materials and there are some differences from the actual
equipment.
★
indicates sections where there are changes compared to the original vehicle.
ITEM
GH-CT9A
Installation height
Upper edge / Lower
edge
675/600
Dipped
headlight
Distance from extreme side of vehicle
155
Installation height
Upper edge / Lower
edge
630/565
Front fog light
*1
Distance from extreme side of vehicle
380
Installation height
Upper edge /
Lower edge
685/615
Road light
Distance from extreme side of vehicle
65
Installation height
Upper edge /
Lower edge
860/765
Tail light (inside)
Distance from extreme side of vehicle
230
Installation height
Upper edge /
Lower edge
840/785
Rear reflector
Distance from extreme side of vehicle
245
Installation height
Upper edge /
Lower edge
855/765
Tail light
(outside)
brake light
Distance from extreme side of vehicle
115
Note
*1 is displayed in the case of a vehicle with discharge type headlight installed.
4-aspect Diagram
The 4-aspect Diagram is included in the application materials and there are some differences from the actual equipment.
Please refer to the Schedule of Lighting Devices for details of lighting devices.
ITEM
GH-CT9A
Installation height
Lower edge
1085
Distance from bottom of window
above
bottom of
window
Auxiliary brake
light
(interior
installation type)
Distance from centre of vehicle
0
Installation height
Upper edge /
Lower edge
610/560
Inner edge distance
1 380
Direction
indicator and
emergency
flashing display
light (front)
Distance from extreme side of vehicle
80
Installation height
Upper edge /
Lower edge
695/665
Direction
indicator
(side)
Distance from forward end of vehicle
★
1 265
Installation height
Upper edge /
Lower edge
745/710
Under floor distance
1 120
Direction
indicator and
emergency
flashing display
light (rear)
Distance from extreme side of vehicle
110
1425 (Interior width)
Driver’s seat
685
Passenger’s
seat 700
1450 (Overall
height)
Sunroof
Without
With
Low back
980
A
High back (Recaro)
1030
995
L/R seat
885
Head clearance
B
Centre seat
865 (880)
840 (875)
Low back
490
C
High back (Recaro)
490
L/R seat
460
Seat depth
D
Centre seat
445 (450)
Low back
500
E
High back (Recaro)
500
Low back
300
Seat space
F
High back (Recaro)
295
Low back
1110
G
High back (Recaro)
1150
Sunroof
Without
With
Interior height
H
1185
1140
