SPECIAL TOOLS
TSB Revision
AUTOMATIC TRANSAXLE
23A-397
STEP 3. Check the lock cam.
Q: Is the lock cam in good condition?
YES :
Go to Step 4.
NO :
Replace the lock cam. Refer to
.
Check that the ignition key can not be
turned to the "LOCK" (OFF) position with
the selector lever at any position other than
"P" position.
STEP 4. Check the fit of the key interlock cable.
Q: Is the key interlock cable installed correctly?
YES :
Go to Step 5.
NO :
Install the key interlock cable correctly.
Refer to
. Check that the ignition
key cannot be turned to the "LOCK" (OFF)
position with the selector lever at any
position other than "P" position.
STEP 5. Check the key interlock cable.
Q: Is the key interlock cable in good condition?
YES :
Go to Step 6.
NO :
Replace the key interlock cable. Refer to
. Check that the ignition key
cannot be turned to the "LOCK" (OFF)
position with the selector lever at any
position other than "P" position.
STEP 6. Check the fit of the transaxle control
cable.
Q: Is the transaxle control cable installed correctly?
YES :
Replace the steering lock cylinder
assembly. Refer to
and
Check that the ignition key can not be
turned to the "LOCK" (OFF) position with
the selector lever at any position other than
"P" position.
NO :
Install the transaxle control cable correctly.
Refer to
. Check that the ignition
key can not be turned to the "LOCK" (OFF)
position with the selector lever at any
position other than "P" position.
SPECIAL TOOLS
M1231000600361
TOOL
TOOL NUMBER AND
NAME
SUPERSESSION APPLICATION
MD998330 (Includes
MD998331)
Oil pressure gauge (3.0
MPa, 427 psi)
MD998330-01
Measurement of hydraulic
pressure
MD998332
Adapter
MD998332-01
Connection for oil pressure
gauge
MD998478
Test harness (3 pin,
triangle)
MD998478-01
Inspection using an oscilloscope
AC103525
