EMISSION CONTROL

TSB Revision

ENGINE AND EMISSION CONTROL

17-97

<3.0L ENGINE

− WITH INTAKE MANIFOLD

TUNING SYSTEM>

AK300700

B : BLACK
G: GREEN

L : LIGHT BLUE

W: WHITE

Y : YELLOW

*1: RED PAINT MARK
*2: RESTRICTOR

EVAPORATIVE
EMISSION
CANISTER

EVAPORATIVE EMISSION
VENTILATION SOLENOID

EGR

VALVE

THROTTLE BODY

VACUUM CONTROL VALVE

FUEL PRESSURE
REGULATOR

EVAPORATIVE EMISSION
PURGE SOLENOID

FRONT

EGR VACUUM REGULATOR
SOLENOID VALVE

INTAKE MANIFOLD
TUNING SOLENOID

INTAKE MANIFOLD
TUNING ACTUATOR

VACUUM TANK

AB

B

B

B

B

B

B

B

B

G

W

W

G

Y

Y

Y

*1

*1

*1

*2

L

G

B

W

EMISSION CONTROL

TSB Revision

ENGINE AND EMISSION CONTROL

17-98

VACUUM CIRCUIT DIAGRAM

M1173007100229

<2.4L ENGINE>

AK300566

THROTTLE BODY

INTAKE MANIFOLD

FROM
AIR CLEANER

TO
COMBUSTION
CHAMBER

AD

EGR VACUUM REGULATOR
SOLENOID VALVE
(ON: CLOSE)

FUEL PRESSURE
REGULATOR

EVAPORATIVE EMISSION
PURGE SOLENOID
(ON: OPEN)

VACUUM
CONTROL
VALVE

EGR VALVE

FUEL
TANK

EVAPORATIVE EMISSION
CANISTER

B : BLACK
G: GREEN
L : LIGHT BLUE

W: WHITE

Y : YELLOW

*1: RED PAINT MARK
*2: RESTRICTOR

EVAPORATIVE EMISSION
VENTILATION SOLENOID
(ON: CLOSE)

L

B

B

B

B

B

G

G

W

Y

Y

*1

*2

*1

EMISSION CONTROL

TSB Revision

ENGINE AND EMISSION CONTROL

17-99

<3.0L ENGINE

− WITHOUT INTAKE

MANIFOLD TUNING SYSTEM>

AK300568

THROTTLE BODY

INTAKE MANIFOLD

FROM
AIR CLEANER

TO
COMBUSTION
CHAMBER

AB

FUEL PRESSURE
REGULATOR

B : BLACK
G: GREEN
L : LIGHT BLUE

W: WHITE

Y : YELLOW

*1: RED PAINT MARK
*2: RESTRICTOR

B

L

G

G

B

B

B

EGR VACUUM REGULATOR
SOLENOID VALVE
(ON: CLOSE)

VACUUM
CONTROL
VALVE

EGR VALVE

B

B

W

Y

B

*2

EVAPORATIVE EMISSION
PURGE SOLENOID
(ON: OPEN)

FUEL
TANK

EVAPORATIVE EMISSION
CANISTER

EVAPORATIVE EMISSION
VENTILATION SOLENOID
(ON: CLOSE)

B

B

*1

*1

B

EMISSION CONTROL

TSB Revision

ENGINE AND EMISSION CONTROL

17-100

<3.0L ENGINE

− WITH INTAKE MANIFOLD

TUNING SYSTEM>

VACUUM HOSE INSTALLATION

M1173007200022

1. When connecting the vacuum hoses, they should be

securely inserted onto the nipples.

2. Connect the hoses correctly, using the VACUUM HOSE

ROUTING as a guide.

AK300701

THROTTLE BODY

INTAKE MANIFOLD

FROM
AIR CLEANER

TO
COMBUSTION
CHAMBER

AB

FUEL PRESSURE
REGULATOR

B : BLACK
G: GREEN
L : LIGHT BLUE

W: WHITE

Y : YELLOW

*1: RED PAINT MARK
*2: RESTRICTOR

B

G

G

B

B

EGR VACUUM REGULATOR
SOLENOID VALVE
(ON: CLOSE)

VACUUM
CONTROL
VALVE

EGR VALVE

B

B

W

Y

B

*2

EVAPORATIVE EMISSION
PURGE SOLENOID
(ON: OPEN)

FUEL
TANK

EVAPORATIVE EMISSION
CANISTER

EVAPORATIVE EMISSION
VENTILATION SOLENOID
(ON: CLOSE)

B

*1

*1

B

B

L

INTAKE
MANIFOLD
TUNING
SOLENOID
(ON: OPEN)

INTAKE MANIFOLD
TUNING ACTUATOR

B

W

W

B

B

Y

VACUUM
TANK
