MULTIPORT FUEL INJECTION (MFI) DIAGNOSIS

TSB Revision

MULTIPORT FUEL INJECTION (MFI) <3.0L>

13B-1083

51

55

Barometric
pressure sensor

Ignition switch:
"ON"

When altitude is 0 m (0 ft)

3.7

− 4.3 volts

When altitude is 600 m
(1,969 ft)

3.4

− 4.0 volts

When altitude is 1,200 m
(3,937 ft)

3.2

− 3.8 volts

When altitude is 1,800 m
(5,906 ft)

2.9

− 3.5 volts

50

56

Camshaft position
sensor

Engine: cranking

0.4

− 3.0 volts

Engine: idling

0.5

− 2.0 volts

68

58

Ignition switch-ST Engine: cranking

8 volts or more

65

61

A/C switch 2

• Engine: idling

• Outside air

temperature:
25

°C or more

When A/C is maximum
cooling condition (when
the load by A/C is high)

B+

When A/C is maximum
heating condition (when
the load by A/C is low)

1 volt or less

62

64

Intake air
temperature
sensor

Ignition switch:
"ON"

When Intake air
temperature is

−20°C

(

−4°F)

3.8

− 4.4 volts

When Intake air
temperature is 0

°C (32°F)

3.2

− 3.8 volts

When Intake air
temperature is 20

°C (68°F)

2.3

− 2.9 volts

When Intake air
temperature is 40

°C

(104

°F)

1.5

− 2.1 volts

When Intake air
temperature is 60

°C

(140

°F)

0.8

− 1.4 volts

When Intake air
temperature is 80

°C

(176

°F)

0.4

− 1.0 volt

61

65

Volume airflow
sensor

Engine: idling

2.2

− 3.2 volts

Engine: 2,500 r/min

60

66

Backup power
supply

Ignition switch: "LOCK" (OFF)

B+

71

71

Left bank heated
oxygen sensor
(front)

• Engine: warming up, 2,500 r/min (check

using a digital voltmeter)

0

⇔ 0.8 volt

(changes
repeatedly)

72

72

Right bank
heated oxygen
sensor (front)

• Engine: warming up, 2,500 r/min (check

using a digital voltmeter)

0

⇔ 0.8 volt

(changes
repeatedly)

73

73

Left bank heated
oxygen sensor
(rear)

• Engine: warming up

• Revving

0 and 0.6

− 1.0

volt alternates

TERMINAL
NO. <M/T>

TERMINAL
NO. <A/T>

INSPECTION ITEM INSPECTION CONDITION (ENGINE

CONDITION)

NORMAL
CONDITION

MULTIPORT FUEL INJECTION (MFI) DIAGNOSIS

TSB Revision

MULTIPORT FUEL INJECTION (MFI) <3.0L>

13B-1084

74

74

Right bank
heated oxygen
sensor (rear)

• Engine: warming up

• Revving

0 and 0.6

− 1.0

volt alternates

78

78

Throttle position
sensor

Ignition switch:
"ON" (check for
smooth voltage
increase as
throttle is moved
from idle position
to wide open
throttle)

Idling

0.535

− 0.735

volt

Wide open throttle

4.5

− 5.5 volts

79

79

Idle position
signal

Ignition switch:
"ON"

Set throttle valve to idle
position

0

− 1 volt

Open throttle slightly

4 volts or more

80

−

Vehicle speed
sensor

• Ignition switch: "ON"

• Move the vehicle slowly forward

0

⇔ 8 −12 volts

(changes
repeatedly)

83

83

A/C switch

Engine: idling

Turn the A/C switch OFF

1 volt or less

Turn the A/C switch ON
(A/C compressor is
operating)

B+

92

91

Manifold absolute
pressure sensor

Engine stopped [At altitude of 0 m (0 ft.)]

3.8 - 4.2 volts

Engine stopped [At altitude of 600 m (1,969
ft.)]

3.5 - 3.9 volts

Engine stopped [At altitude of 1,200 m (3,937
ft.)]

3.3 - 3.7 volts

Engine stopped [At altitude of 1,800 m (5,906
ft.)]

3.0 - 3.4 volts

Engine: idling

0.8

− 2.4 volts

• Engine: idling

• Suddenly depress the accelerator pedal

varies

93

92

Fuel tank
differential
pressure sensor

Engine: idling

1.2

− 3.8 volts

99

98

Ignition switch-IG Ignition switch: "ON"

B+

TERMINAL
NO. <M/T>

TERMINAL
NO. <A/T>

INSPECTION ITEM INSPECTION CONDITION (ENGINE

CONDITION)

NORMAL
CONDITION

MULTIPORT FUEL INJECTION (MFI) DIAGNOSIS

TSB Revision

MULTIPORT FUEL INJECTION (MFI) <3.0L>

13B-1085

TERMINAL RESISTANCE AND CONTINUITY CHECK

AK000059

ECM <M/T> or PCM <A/T> Connector Terminal Arrangement

<M/T>

<A/T>

AB

78

91

71

59

68

47

58

67

56

66

55 54

65

53

64

52

63

46

51

62

44

49

61

42

48

60

41

23

35

8

22 21

34

7

20

33

6

19

32

18

31

17 16

30

15

29

14

28

5

13

27

4

12 11

26

3

10

25

2

9

24

1

23

35

8

47

58

41

48

59

50

60

51

61

52

62

53

54

63

42

55

64

44

56

65

45

57

66

46

78

90

71

79

91

72

81

92

82

93

83

84

94

85

95

86

96

74

88

97

76

89

98

77

108

121

101

109

122

110

123

102

112

124

113

114

125

115

126

116

127

117

128

104

119

129

106

120

130

107

118

105

111

103

87

75

80

73

49

43

22 21

34

7

20

33

6

19

32

18

31

17 16

30

15

29

14

28

5

13

27

4

12 11

26

3

10

25

2

9

24

1

50

43

57

45

79

92

80

93

83

84

95

86

97

87

98

89

99

72

82

94

74

85

96

76

90

100

77

88

75

81

73

TERMINAL
NO. <M/T>

TERMINAL
NO. <A/T>

INSPECTION ITEM

NORMAL CONDITION (INSPECTION
CONDITION)

1

− 47

1

− 41

No.1 injector

13

− 16 ohms [at 20°C (68°F)]

9

− 47

9

− 41

No.2 injector

24

− 47

24

− 41

No.3 injector

2

− 47

2

− 41

No.4 injector

10

− 47

10

− 41

No.5 injector

25

− 47

25

− 41

No.6 injector

3

− 47

3

− 41

Left bank heated oxygen sensor
heater (front)

4.5

− 8.0 ohms [at 20°C (68°F)]

4

− 47

4

− 41

Right bank heated oxygen sensor
heater (front)

4.5

− 8.0 ohms [at 20°C (68°F)]

6

− 47

6

− 41

EGR vacuum regulator solenoid
valve

29

− 35 ohms [at 20°C (68°F)]

14

− 47

14

− 41

Stepper motor coil (A1)

28

− 33 ohms [at 20°C (68°F)]

28

− 47

28

− 41

Stepper motor coil (A2)

15

− 47

15

− 41

Stepper motor coil (B1)

29

− 47

29

− 41

Stepper motor coil (B2)

26

− 47

26

− 41

Left bank heated oxygen sensor
heater (rear)

11

− 18 ohms [at 20°C (68°F)]

27

− 47

27

− 41

Right bank heated oxygen sensor
heater (rear)

11

− 18 ohms [at 20°C (68°F)]

16

− 47

34

− 41

Evaporative emission purge
solenoid

30

− 34 ohms [at 20°C (68°F)]

35

− 47

35

− 41

Evaporative emission ventilation
solenoid

17

− 21 ohms [at 20°C (68°F)]

46

− Body

ground

42

− Body

ground

ECM or PCM ground

Continuity (2 ohm or less)

58

− Body

ground

48

− Body

ground

ECM or PCM ground

MULTIPORT FUEL INJECTION (MFI) DIAGNOSIS

TSB Revision

MULTIPORT FUEL INJECTION (MFI) <3.0L>

13B-1086

INSPECTION PROCEDURE USING AN OSCILLOSCOPE

M1131154500598

VOLUME AIRFLOW SENSOR

Required Special Tool:

• MB991709: Test Harness

.

Measurement Method
1. Disconnect the volume airflow sensor connector, and

connect the test harness special tool (MB991709) in
between. (All terminals should be connected.)

2. Connect the oscilloscope probe to volume airflow sensor

connector terminal 3.

.

Alternate method (Test harness not available)

<M/T>

1. Connect the oscilloscope probe to ECM terminal 61.

<A/T>

1. Connect the oscilloscope probe to PCM terminal 65.

44

− 49

44

− 57

Engine coolant temperature sensor

14

− 17 kΩ [when engine coolant

temperature is

−20°C (−4°F)]

5.1

− 6.5 kΩ [when engine coolant

temperature is 0

°C (32°F)]

2.1

− 2.7 kΩ [when engine coolant

temperature is 20

°C (68°F)]

0.9

− 1.3 kΩ [when engine coolant

temperature is 40

°C (104°F)]

0.48

− 0.68 kΩ [when engine coolant

temperature is 60

°C (140°F)]

0.26

− 0.36 kΩ [when engine coolant

temperature is 80

°C (176°F)]

32

− 47

53

− 41

Intake manifold tuning solenoid

29

− 35 ohms [at 20°C (68°F)]

62

− 49

64

− 57

Intake air temperature sensor

13

− 17 kΩ [when intake air temperature is

−20°C (−4°F)]
5.3

− 6.7 kΩ [when intake air temperature

is 0

°C (32°F)]

2.3

− 3.0 kΩ [when intake air temperature

is 20

°C (68°F)]

1.0

− 1.5 kΩ [when intake air temperature

is 40

°C (104°F)]

0.56

− 0.76 kΩ [when intake air

temperature is 60

°C (140°F)]

0.30

− 0.42 kΩ [when intake air

temperature is 80

°C (176°F)]

TERMINAL
NO. <M/T>

TERMINAL
NO. <A/T>

INSPECTION ITEM

NORMAL CONDITION (INSPECTION
CONDITION)

AK302581

1 2 3 4 5 6 7

AB

VOLUME AIRFLOW
SENSOR CONNECTOR

OSCILLOSCOPE

MB991709
