MULTIPORT FUEL INJECTION (MFI) DIAGNOSIS

TSB Revision

MULTIPORT FUEL INJECTION (MFI) <2.4L>

13A-609

NOTE: Check harness after checking intermediate connectors
C-90, and C-28. If intermediate connectors are damaged,
repair or replace them. Refer to GROUP 00E, Harness Con-
nector Inspection

P.00E-2

. Then go to Step 6.

Q: Is the harness wire in good condition?

YES : Refer to GROUP 54A, Chassis Electrical -

Combination Meters Assembly and Vehicle Speed
Sensor - Equipment Diagnosis - Symptom Chart

P.54A-44

.

NO :  Repair it. Then go to Step 6.

STEP 3. Check connector C-60 at ECM <M/T> or connector
C-54 at PCM <A/T> for damage.
Q: Is the connector in good condition?

YES : Go to Step 4.
NO :  Repair or replace it. Refer to GROUP 00E, Harness

Connector Inspection

P.00E-2

. Then go to Step 6.

AK300415

82

78

8180

89

90

91

92

79

87

71

74 73 72

76 75

77

85

88

83

84

86

CONNECTOR: C-60 <M/T>

AB

C-60 (G)

HARNESS CONNECTOR:
COMPONENT SIDE

AK300412

42

43

48

49

50

51

52

53

54

55

56

57

46 45 44

58

59

60

61

62

63

64

65

66

47

41

C-54 (GR)

CONNECTOR: C-54 <A/T>

AB

HARNESS CONNECTOR:
COMPONENT SIDE

MULTIPORT FUEL INJECTION (MFI) DIAGNOSIS

TSB Revision

MULTIPORT FUEL INJECTION (MFI) <2.4L>

13A-610

STEP 4. Check for open circuit or harness damage
between fuel level sensor connector D-17 (terminal No. 2)
and ECM connector C-60 (terminal No. 74) <M/T> or PCM
connector C-54 (terminal No. 60) <A/T>.

AK300453

1

2

3

4

5

D-17 (GR)

AB

CONNECTOR: D-17

HARNESS CONNECTOR:
COMPONENT SIDE

AK300415

82

78

8180

89

90

91

92

79

87

71

74 73 72

76 75

77

85

88

83

84

86

CONNECTOR: C-60 <M/T>

AB

C-60 (G)

HARNESS CONNECTOR:
COMPONENT SIDE

AK300412

42

43

48

49

50

51

52

53

54

55

56

57

46 45 44

58

59

60

61

62

63

64

65

66

47

41

C-54 (GR)

CONNECTOR: C-54 <A/T>

AB

HARNESS CONNECTOR:
COMPONENT SIDE

MULTIPORT FUEL INJECTION (MFI) DIAGNOSIS

TSB Revision

MULTIPORT FUEL INJECTION (MFI) <2.4L>

13A-611

NOTE: Check harness after checking intermediate connectors
C-90, and C-28. If intermediate connectors are damaged,
repair or replace them. Refer to GROUP 00E, Harness Con-
nector Inspection

P.00E-2

. Then go to Step 6.

Q: Is the harness wire in good condition?

YES : Go to Step 5.
NO :  Repair it. Then go to Step 6.

STEP 5. Check the trouble symptoms.
(1) Carry out a test drive with the drive cycle pattern. Refer to

Diagnostic Function

− OBD-II Drive Cycle − Procedure 6 −

Other Monitor

P.13A-5

.

(2) Check the diagnostic trouble code (DTC).
Q: Is DTC P0461 set?

YES : Replace the ECM or PCM. Then go to Step 6.
NO :  It can be assumed that this malfunction is intermittent.

Refer to GROUP 00, How to Use
Troubleshooting/Inspection Service Points

P.00-6

.

STEP 6. Test the OBD-II drive cycle.
(1) Carry out a test drive with the drive cycle pattern. Refer to

Diagnostic Function

− OBD-II Drive Cycle − Procedure 6 −

Other Monitor

P.13A-5

.

(2) Check the diagnostic trouble code (DTC).
Q: Is DTC P0461 set?

YES :  Retry the troubleshooting.
NO :  The inspection is complete.

MULTIPORT FUEL INJECTION (MFI) DIAGNOSIS

TSB Revision

MULTIPORT FUEL INJECTION (MFI) <2.4L>

13A-612

DTC P0500: Vehicle Speed Sensor Malfunction <M/T>

AK103267

3

1

2 3

3

2

4 5 6

1 2 3
4 5 6

1

WHITE

BLUE

WHITE-

BLUE

WHITE-

BLUE

BLA

CK

BLA

CK

7 8

5

3 4

35

34

10 11 12

2122 23 24

13 14 15

25 26 27

16

28

17

18 19 20

29

30 31

32 33

36 37

38

9

1 2

16

15

18

17

14

20

22

21

9

7

1 2

5

19

3

33

32

30 31

29

28

25

24

23

27

26

6

11

13

4

10

8

BLA

CK-

WHITE

BLA

CK-

WHITE

BLA

CK-

WHITE

BLA

CK-

WHITE

GREEN

1

12

6

2

     C-60
(MU803772)

AUTO-CRUISE
 CONTROL SYSTEM
CENTRAL DOOR
 LOOKING SYSTEM
DOME LIGHT, LUGGAGE
 COMPARTMENT LIGHT
 AND TRUNK LIGHT
 (ECLIPSE SPYDER)
METER AND
 GAUGE
MULTI CENTER
 DISPLAY

5 V

     B-39
(MU802723)

VEHICLE SPEED
SENSOR

B-36

86

ENGINE CONTROL
MODULE (ECM)

R

IG2

ST

LOCK

ACC

IG1

    C-111
MU801331

IGNITION
SWITCH

Vehicle Speed Sensor Circuit

C-87

2

6

11

1

2

2

3

3

C-28

C-78

1

4

4

1

JOINT
CONNECTOR (2)

JUNCTION
BLOCK

82

78

81

80

89 90 91 92

79

87

71

74

73

72

76

75

77

85

88

83 84

86

1

6

4 5

11

10

12 13 14

8 9

7

2 3

C-112

MU801857

23

7.5A
