TAILGATE TRIM

INTERIOR

52A-16

TAILGATE TRIM

REMOVAL AND INSTALLATION

M1521006500083

AC303037

A

A

B

B

C

C

D

D

5

6

6

1

2

3

4

E

E

5

6

5

6

5

6

4

AB

NOTE
(1)          : Clip position
(2)          : Claw position

Section A – A

Section B – B

Section C – C

Section D – D

Section E – E

Claw

Claw

Clip

Clip

Clip

Removal steps

1.

lens

2.

Luggage room lamp

3.

Tailgate grip

4.

Lower tailgate trim

5.

Upper tailgate trim

6.

Tailgate opening side trim

Removal steps (Continued)

HEADLINING

INTERIOR

52A-17

HEADLINING

REMOVAL AND INSTALLATION

M1521001400326

CAUTION

For the removal of the headlining, refer to GROUP 52B, Service Precautions

P.52B-7

 and Side and

Curtain Air Bag Module

P.52B-231

.

AC311006

5

6

3

4

7

4

3

2

10

1

2

2

11

12

A

A

C

C

9

9

AB

9

1

7

D

D

8

8

NOTE
          : Clip position

Section A – A

Section B – B

Section C – C

Clip

Clip

Clip

Clip

Clip

Clip

Front room lamp
bracket

Removal steps

•

Third seat assembly (Refer to

P.52A-33

).

•

Quarter trim upper, centre pillar trim
upper, front pillar trim (Refer to

P.52A-10

).

1.

Rear heater controller assembly

2.

Roof inside assist grip

3.

Sun visor

<<A>>

4.

Sun visor holder

5.

Sun roof lid inner weather lid
<Vehicles with sunroof>

6.

Sunroof lid inner weather strip rear
<Vehicles with sunroof>

<<B>>

7.

Front room lamp assembly
<Vehicles without sunroof>

<<B>>

8.

Front room lamp assembly
<Vehicles with sunroof>

<<C>>

9.

Headlining assembly

10. Assist grip bracket front

Removal steps (Continued)

HEADLINING

INTERIOR

52A-18

REMOVAL SERVICE POINTS
<<A>> SUNVISOR HOLDER REMOVAL

Use a flat-tipped screwdriver to disengage the tab of
the sunvisor holder, and remove it using moderate
pressure from the forefinger and thumb.

<<B>> FRONT ROOM LAMP ASSEMBLY
REMOVAL

Slide down the front room lamp assembly by pushing
it forwards to disengage the front room lamp
assembly from the front room lamp bracket. Then
remove the front room lamp assembly.

<<C>> HEADLINING ASSEMBLY
REMOVAL

The following tools are recommended for removing
the headlining assembly.

Ornament remover set (parts number JS000004)
1. Remover A (parts number JS000001)
2. Remover B (parts number JS000003)
3. Remover C (parts number JS000002)

11. Assist grip bracket centre
12. Assist grip bracket rear

Removal steps (Continued)

AC208653

(–) screw driver

Sunvisor holder

AB

Sunvisor holder

AC303132

A

A

Front room lamp assembly

Front room lamp
assembly

Headlining room
assembly

Clip

Clip

Front room lamp bracket

AB

Section A – A

AC303685

3

2

1

AB

HEADLINING

INTERIOR

52A-19

Use the recommended tool Remover C (parts
number JS000002) as shown to remove the clip.

DISASSEMBLY AND REASSEMBLY

M1521009100028

AC303706 AB

Recommended tool
Remover C
(parts number JS000002)

Clip

AC311012

1

1

2

AB

Disassembly steps

1.

Rear personal lamp

2.

Headlining
