DIAGNOSTIC TROUBLE CODE PROCEDURES

SMART WIRING SYSTEM (SWS) NOT USING SWS MONITOR

54B-53

Step 10. Connector check: C-221 ETACS-ECU
connector

Q: Is the check result normal?

YES :

Go to Step 11.

NO :

Repair the defective connector.

AC310626

Connector: C-221

Junction block (Rear view)

<LHD>

AC

51

52

53

54

55

56

57

58

59

60

61

62

63

64

65

66

67

68

69

70

71

72

73

74

Harness side

C-221(GR)

AC310620

Connector: C-221

Junction block
(Rear view)

<RHD>

AC

51

52

53

54

55

56

57

58

59

60

61

62

63

64

65

66

67

68

69

70

71

72

73

74

Harness side

C-221(GR)

DIAGNOSTIC TROUBLE CODE PROCEDURES

SMART WIRING SYSTEM (SWS) NOT USING SWS MONITOR

54B-54

Step 11. Check the wiring harness between E-07
sunroof motor assembly connector terminal
No.10 and C-221 ETACS-ECU connector terminal
No.59.

NOTE: Prior to the wiring harness inspection, check
joint connector C-01 and intermediate connector
C-128, and repair if necessary.

• Check the communication lines for open circuit.

Q: Is the check result normal?

YES :

Go to Step 12.

NO :

Repair the wiring harness.

AC310651

AB

Connector: E-07 <LHD>

Harness side

AC310655

AC

Connector: E-07 <RHD>

Harness side

AC310626

Connector: C-221

Junction block (Rear view)

<LHD>

AC

51

52

53

54

55

56

57

58

59

60

61

62

63

64

65

66

67

68

69

70

71

72

73

74

Harness side

C-221(GR)

AC310620

Connector: C-221

Junction block
(Rear view)

<RHD>

AC

51

52

53

54

55

56

57

58

59

60

61

62

63

64

65

66

67

68

69

70

71

72

73

74

Harness side

C-221(GR)

AC310614

AX

Connectors: C-01, C-128 <LHD>

C-128

C-128

C-01

C-01

AC310632AQ

Connectors: C-01, C-128 <RHD>

C-01

C-128

C-01

C-128

DIAGNOSTIC TROUBLE CODE PROCEDURES

SMART WIRING SYSTEM (SWS) NOT USING SWS MONITOR

54B-55

Step 12. Check whether the diagnosis code is
reset.

Replace the sunroof motor assembly (sunroof-ECU),
and then check that the diagnosis code is not reset.
(1) Replace the sunroof motor assembly

(sunroof-ECU).

(2) Ignition switch: ON
(3) On completion, check that diagnosis code No.04

is not reset.

Q: Is diagnosis code No.04 set?

YES :

Replace the ETACS-ECU.

NO :

The procedure is complete.

DIAGNOSTIC TROUBLE CODE PROCEDURES

SMART WIRING SYSTEM (SWS) NOT USING SWS MONITOR

54B-56

Diagnosis code No.05 Communication error with power window main switch

CAUTION

If diagnosis code No.05 is set in the ETACS-ECU,
diagnose the CAN bus lines.

Power Window Main Switch and SWS Communication Circuit <LHD>

POWER
WINDOW RELAY

ETACS-ECU

DIAGNOSIS
CONNECTOR

POWER WINDOW
MAIN SWITCH

FUSIBLE
LINK

5

CPU

J/B SIDE

Wire colour code
B : Black     LG : Light green     G : Green     L : Blue
W : White     Y : Yellow     SB : Sky blue     BR : Brown
O : Orange     GR : Gray     R : Red     P : Pink     V : Violet

FRONT
SIDE
