CRUISE CONTROL SYSTEM

CIRCUIT DIAGRAMS

90-177

CRUISE CONTROL SYSTEM <RHD>

M1901032901917

23

FUSIBLE
LINK

RELAY
BOX

ENGINE
CONTROL
RELAY

POWER
SOURCE

·ENGINE
 CONTROL
 SYSTEM
·GLOW
 SYSTEM

20

FUSIBLE
LINK

IGNITION
SWITCH (IG1)

COMBINATION
METER

BATTERY
BACK-UP

ENGINE-
ECU

ACCELERATOR
PEDAL
POSITION
SENSOR

HALL IC

(MAIN)

HALL IC

(SUB)

THROTTLE
VALVE
CONTROL
SERVO

THROTTLE POSITION
SENSOR

ELECTRONIC-CONTROLLED
THROTTLE VALVE

HALL IC

HALL IC

ENGINE-
ECU

CRUISE CONTROL SYSTEM

CIRCUIT DIAGRAMS

90-178

CRUISE CONTROL SYSTEM <RHD> (CONTINUED)

VEHICLE SPEED
SENSOR

<M/T>

CLUTCH
SWITCH

STOP LAMP

ELC-4A/T

RELAY BOX

(FUSE     )

12

STOP
LAMP
SWITCH

ENGINE-ECU

ENGINE
CONTROL
RELAY

CLOCK
SPRING

ENGINE-ECU

CRUISE
CONTROL
SWITCH

·MMCS
·RADIO AND
 CD PLAYER
·SPARE CONNECTOR
 (FOR AUDIO)

TAIL LAMP
RELAY

ETACS-
ECU

J/B SIDE

CRUISE CONTROL SYSTEM <RHD> (CONTINUED)

DIAGNOSIS
CONNECTOR

(FUSE     )

12

ENGINE-ECU

A/T-ECU

<A/T>

<VEHICLES WITH ASTC>

ASTC-ECU

FRONT
SIDE

INPUT SIGNAL

INHIBITOR
SWITCH (N)

USB BOX

CIRCUIT DIAGRAMS

90-179

USB BOX

M1901035000664

FUSIBLE
LINK

20

POWER
SOURCE

Wire colour code
B : Black     LG : Light green     G : Green     L : Blue     W : White     Y : Yellow     SB : Sky blue
BR : Brown     O : Orange     GR : Grey     R : Red     P : Pink     V : Violet     PU : Purple     SI : Silver

USB BOX

USB
CONNECTOR

TAIL LAMP
RELAY

ETACS-
ECU

J/B SIDE

NOTE

LHD
RHD

USB CABLE

USB BOX

CIRCUIT DIAGRAMS

90-180

USB BOX (CONTINUED)

CLOCK
SPRING

RADIO AND CD PLAYER

CRUISE
CONTROL
SYSTEM

STEERING
WHEEL
AUDIO
REMOTE
CONTROL
SWITCH

(FUSE     )

7

CLOCK
SPRING

MULTIVISION DISPLAY

CRUISE
CONTROL
SYSTEM

STEERING
WHEEL
AUDIO
REMOTE
CONTROL
SWITCH

(FUSE     )

7

Wire colour code
B : Black     LG : Light green     G : Green     L : Blue     W : White     Y : Yellow     SB : Sky blue
BR : Brown     O : Orange     GR : Grey     R : Red     P : Pink     V : Violet     PU : Purple     SI : Silver

<VEHICLES WITH
AUDIO SYSTEM>

<VEHICLES WITH MMCS>

USB BOX (CONTINUED)

RADIO AND CD PLAYER

AUDIO AMPLIFIER

<VEHICLES WITH AUDIO SYSTEM>

USB BOX

<VEHICLES WITH
AUDIO AMPLIFIER>

Wire colour code
B : Black     LG : Light green     G : Green     L : Blue     W : White     Y : Yellow     SB : Sky blue
BR : Brown     O : Orange     GR : Grey     R : Red     P : Pink     V : Violet     PU : Purple     SI : Silver

OUTPUT SIGNAL

·FRONT DOOR SPEAKER
·TWEETER
·REAR DOOR SPEAKER

OUTPUT SIGNAL

·FRONT DOOR SPEAKER
·TWEETER
·REAR DOOR SPEAKER

<VEHICLES WITHOUT
AUDIO AMPLIFIER>
