CENTRAL DOOR LOCKING SYSTEM

CIRCUIT DIAGRAMS

90-101

CENTRAL DOOR LOCKING SYSTEM <VEHICLES WITHOUT KEYLESS ENTRY SYSTEM (LHD)> (CON-
TINUED)

FRONT
SIDE

ETACS-
ECU

DIAGNOSIS
CONNECTOR

(FUSE     )

12

J/B SIDE

IMPACT
DETECTION DOOR
UNLOCK SIGNAL
PROCESSING
CIRCUIT

SRS-ECU

NOTE

:
:

VEHICLES WITHOUT SIDE-AIRBAG
VEHICLES WITH SIDE-AIRBAG

CENTRAL DOOR LOCKING SYSTEM

CIRCUIT DIAGRAMS

90-102

CENTRAL DOOR LOCKING SYSTEM
<VEHICLES WITHOUT KEYLESS ENTRY
SYSTEM (RHD)>

M1901004707613

FUSIBLE
LINK

20

IGNITION
SWITCH (IG1)

POWER
SOURCE

FRONT
DOOR LOCK
ACTUATOR
(RH)

REAR
DOOR LOCK
ACTUATOR
(LH)

DOOR UNLOCK
RELAY

DOOR LOCK
RELAY

ETACS-
ECU

REAR
DOOR LOCK
ACTUATOR
(RH)

J/B SIDE

<DOUBLE CAB>

FRONT
DOOR LOCK
ACTUATOR
(LH)

Wire colour code
B : Black     LG : Light green     G : Green     L : Blue     W : White     Y : Yellow     SB : Sky blue
BR : Brown     O : Orange     GR : Grey     R : Red     P : Pink     V : Violet     PU : Purple     SI : Silver

CENTRAL DOOR LOCKING SYSTEM

CIRCUIT DIAGRAMS

90-103

CENTRAL DOOR LOCKING SYSTEM <VEHICLES WITHOUT KEYLESS ENTRY SYSTEM (RHD)> (CON-
TINUED)

FRONT
SIDE

ETACS-
ECU

DIAGNOSIS
CONNECTOR

(FUSE     )

12

J/B SIDE

IMPACT
DETECTION DOOR
UNLOCK SIGNAL
PROCESSING
CIRCUIT

SRS-ECU

NOTE

:
:

VEHICLES WITHOUT SIDE-AIRBAG
VEHICLES WITH SIDE-AIRBAG

CENTRAL DOOR LOCKING SYSTEM

CIRCUIT DIAGRAMS

90-104

CENTRAL DOOR LOCKING SYSTEM
<VEHICLES WITH KEYLESS ENTRY
SYSTEM (LHD)>

M1901004707624

FUSIBLE
LINK

20

IGNITION
SWITCH (IG1)

POWER
SOURCE

FRONT
DOOR LOCK
ACTUATOR
(LH)

FRONT
DOOR LOCK
ACTUATOR
(RH)

REAR
DOOR LOCK
ACTUATOR
(LH)

DOOR UNLOCK
RELAY

DOOR LOCK
RELAY

ETACS-
ECU

REAR
DOOR LOCK
ACTUATOR
(RH)

J/B SIDE

<DOUBLE CAB>

Wire colour code
B : Black     LG : Light green     G : Green     L : Blue     W : White     Y : Yellow     SB : Sky blue
BR : Brown     O : Orange     GR : Grey     R : Red     P : Pink     V : Violet     PU : Purple     SI : Silver
