Mitsubishi L200. Manual - part 710





HIGH-MOUNTED STOP LAMP

CHASSIS ELECTRICAL

54A-207

HIGH-MOUNTED STOP LAMP

REMOVAL AND INSTALLATION

M1541700200030

LICENCE PLATE LAMP

SPECIAL TOOL

M1541900300019

AC502777AB

1

2

4.9 ± 0.7 N·m

3

4

High-mounted stop lamp
removal steps

•

Rear gate cover (Refer to GROUP
42, Rear gate .)

1.

Rear gate outside handle

2.

High-mounted stop lamp

3.

Socket

4.

Bulb

High-mounted stop lamp
removal steps (Continued)

Tool

Number

Name

Use

MB990784

Ornament
remover

Removal of licence plate lamp
assembly

MB990784

LICENCE PLATE LAMP

CHASSIS ELECTRICAL

54A-208

REMOVAL AND INSTALLATION

M1541900200465

<VEHICLES WITH REAR BODY>

<VEHICLES WITHOUT REAR BODY>

AC502796AB

1

2

3

4

Removal steps

<<

A

>>

1.

Licence plate lamp assembly

2.

Socket

3.

Bulb

4.

Licence plate lamp unit

AC903484AB

2

4

3

5

6

7

1

8

4.9 ± 0.7 N·m

4.9 ± 0.7 N·m

4.9 ± 0.7 N·m

1.5 ± 0.4 N·m

Removal steps

1.

Licence plate lamp assembly

2.

Cover

3.

Lens

4.

Gasket

5.

Bulb

6.

Licence plate lamp base

Removal steps (Continued)

LICENCE PLATE LAMP

CHASSIS ELECTRICAL

54A-209

<VEHICLES FOR MOROCCO
(OPTIONAL)>

7.

Dummy bracket

8.

Licence plate lamp bracket
assembly

Removal steps (Continued)

AC600253

AC600255

AC600254

ACB01679

AB

1

2

3

4

5

6

7

Rear step bumper

1.5 ± 0.4 N·m

Section A - A

Section B - B

A

A

B

B

1

7

Rear step bumper

Rear step bumper

7

N

Claw

NOTE
       : Claw position

Claw

Claw

Removal steps

1.

Harness band

2.

Licence plate lamp assembly

3.

Cover

4.

Lens

5.

Gasket

6.

Bulb

7.

Licence plate lamp base

Removal steps (Continued)

LICENCE PLATE LAMP

CHASSIS ELECTRICAL

54A-210

REMOVAL SERVICE POINT

<<A>> LICENCE PLATE LAMP ASSEMBLY
REMOVAL

Use special tool ornament remover (MB990784) to
press the licence plate assembly to the direction
shown (inside the vehicle), and shorten the claw B
and disengage the claw A. Then remove the licence
plate lamp assembly.

AC502810

AB

MB990784

Section A – A

Claw A

Claw B

MB990784

A

A
