HEADLAMP

CHASSIS ELECTRICAL

54A-147

LIGHTING CONTROL SENSOR REMOVAL AND INSTALLATION

M1540108500267

REMOVAL SERVICE POINT

<<A>> LIGHTING CONTROL SENSOR REMOVAL

While pushing the clamp to the windshield side, pry
up the clamp to disengage the right and left claws
using the flat-tipped screwdriver, and then remove
the lighting control sensor.

INSTALLATION SERVICE POINT

>>A<< LIGHTING CONTROL SENSOR INSTALLA-
TION

CAUTION

After executing the lighting control sensor (rain
sensor) adaptation, do not touch the lighting
control sensor (or do not move it from the fixed
position).

• Mount the lighting control sensor onto the optical

coupler, and then connect the connector.

AC807278

Optical coupler

AB

1

2

3

Note
         : Claw positions

A

A

Section A - A

Section B - B

Section C - C

Section D - D

Optical coupler

3

B

D

C

B

D

C

1

1

1

Claw

Claw

Lighting control
sensor bracket

Lighting control
sensor bracket

Lighting control
sensor bracket

Lighting control
sensor bracket

Claw

Claw

Claw

Removal Steps

1.

Lighting control sensor cover

2.

Connector

<<

A

>>

>>

A

<<

3.

Lighting control sensor

AC700066

Flat-tipped
Screwdriver

AH

Claw

Lighting
control
sensor

Clamp

Push

Push

HEADLAMP

CHASSIS ELECTRICAL

54A-148

• When reusing the lighting control sensor or when

the lighting control sensor is pushed to check the
installation condition, install the connector and
the lighting control sensor cover and wipe the
windshield thoroughly. When the windshield is
dry, execute the lighting control sensor (rain sen-
sor) adaptation. <Refer to GROUP 51

− Lighting

Control Sensor (Rain Sensor) Adaptation >.

NOTE: Be careful not to touch the lighting control
sensor receiver. (The lighting control sensor receiver
has limited resistance to oil.)

INSPECTION

HEADLAMP RELAY CHECK

M1540104000282

HEADLAMP RELAY (LO) CHECK

HEADLAMP RELAY (HI) CHECK

AC502554

AF

4

2

3

1

Headlamp
relay (LO)

4

1

2

3

Battery voltage

Tester
connection

Specified
condition

Not supplied

3

− 4

Open circuit

• Connect terminal 1

to the negative
battery terminal

• Connect terminal 2

to the positive
battery terminal

3

− 4

Continuity
exists (2

Ω

or less)

Battery voltage

Tester
connection

Specified
condition

Not supplied

3

− 4

Open circuit

• Connect terminal 2

to the negative
battery terminal

• Connect terminal 1

to the positive
battery terminal

3

− 4

Continuity
exists (2

Ω

or less)

AC502554

AG

4

1

3

2

Headlamp
relay (HI)

4

1

2

3

FRONT FOG LAMP

CHASSIS ELECTRICAL

54A-149

HEADLAMP LEVELLING SWITCH CHECK

M1540101300035

LIGHTING CONTROL SENSOR (LAMP
SENSOR) CHECK

M1540109000210

Use M.U.T.-III to check the LIN data list as follows.
1. Under the direct sunlight, turn the ignition switch

to the ON position, and turn the lighting switch to
the auto lamp position.

2. When the lighting control sensor receiver is

covered to be darkened, it is judged normal if the
items of No. 7009: RLS Low beam "ON" request
and 7011: RLS Taillamp "ON" request change
from OFF to ON.

NOTE:

.

•

When covering the lighting control sensor
receiver, be careful not to touch the windshield
surface (where the lighting control sensor
receiver is mounted). (The lighting control sensor
receiver has limited resistance to oil.)

•

Before checking the data list by using M.U.T.-III,
wipe the windshield thoroughly and visually
check if there are foreign materials on the wind-
shield to which the lighting control sensor is
installed.

FRONT FOG LAMP

SERVICE SPECIFICATION

M1540400900024

Tester
connection

Switch
position

Resistance value
Ω

4

− 6

0

750

1

1, 050

2

1, 410

3

1, 710

4

2, 010

5

− 6

0, 1, 2, 3, 4

2, 830

AC302750AB

Item

Standard value

Front fog lamp aiming

Vertical direction

60 mm (1.15

°) below horizontal (H)

FRONT FOG LAMP

CHASSIS ELECTRICAL

54A-150

SPECIAL TOOLS

M1540401800020
