AIR BAG MODULE AND SEAT BELT PRE-TENSIONER DISPOSAL PROCEDURES
SUPPLEMENTAL RESTRAINT SYSTEM (SRS)
52B-303
7. At a location as far away from the seat belt pre-
tensioner as possible, and from a shielded
position, disconnect the two connected wires from
each other, and connect them to the two terminals
of the battery (which has been removed from the
vehicle) to operated seat belt pre-tensioner.
8. Discard the operated seat belt pre-tensioner as
specified in Deployed Air Bag Module and Seat
Belt pre-tensioner Disposal (Refer to ).
DEPLOYED AIR BAG MODULE AND
OPERATED SEAT BELT PRE-TEN-
SIONER DISPOSAL
After deployment and operation, the air bag module
and seat belt pre-tensioner should be disposed of in
the same manner as any other scrap parts, adhering
to local laws and/or legislation. Observe the following
precautions during air bag or seat belt pre-tensioner
disposal:
1. The inflator will be quite hot immediately following
deployment, so wait at least 30 minutes to allow it
cool before attempting to handle it.
2. Do not put water or oil on the air bag after
deployment or on the seat belt pre-tensioner after
operation.
WARNING
If after following these precautions, any
material does get into the eyes or on the
skin, immediately rinse the affected area with
a large amount of clean water. If any irritation
develops, seek medical attention.
3. There may be material on the deployed air bag
module or the operated seat belt pre-tensioner,
that could irritate the eye and/or skin. Wear gloves
and safety glasses when handling a deployed air
bag module or the operated seat belt pre-
tensioner.
AC300562 AC
Air bag module and
seat belt pre-tensioner
Strong plastic bag
4. Tightly seal the air bag module and seat belt pre-
tensioner in a strong plastic bag for disposal.
5. Be sure to always wash your hands after
completing this operation.
