AC502417

AB

Headlining

Rear door

INSIDE REAR VIEW MIRROR

INTERIOR

52A-22

To remove the headlining from the vehicle, remove
from the rear door (LH) as shown in the figure. <Dou-
ble cab>

INSIDE REAR VIEW MIRROR

M1521002600431

REMOVAL SERVICE POINT

AC209066

Claw B

Claw A

Cover

1

2

3

AD

1. Disengage the claw A and lower the cover toward

arrow 1 direction.

2. Push the claw B toward arrow 2 direction to

unlock, and pull out the mirror toward arrow 3
direction.

FRONT SEAT ASSEMBLY

REMOVAL AND INSTALLATION

M1522001302061

AC511525AB

4

5

5

44 ± 10 N·m

30 ± 5 N·m

44 ± 10 N·m

30 ± 5 N·m

1

1

<Separate seat>

<Bench seat>

3

2

2

ACA00284

6

AC

1.

Headrestraint
Removal steps

2.

Rear anchor cover

3.

Power seat harness connecter
<Vehicles with power seat>

4.

Seat belt switch connector
<Vehicles for GCC>

>>

A

<<

5.

Front seat assembly
Heated seat switch removal step

6.

Heated seat switch <Vehicles for
Russia>

FRONT SEAT ASSEMBLY

INTERIOR

52A-23

INSTALLATION SERVICE POINT

>>A<< FRONT SEAT ASSEMBLY INSTALLATION

AC509430 AB

1. Confirm that the seat slide is locked. Then

temporarily tighten all the nuts and bolts with no
load applied to the front seat cushion.

2. Tighten all the nuts and bolts to the specified

torque.

Tightening torque:

Bolt: 44

± 10 N⋅m

Nut: 30

± 5 N⋅m

FRONT SEAT ASSEMBLY

INTERIOR

52A-24

DISASSEMBLY AND REASSEMBLY

M1522001502065

<MANUAL SEAT>

AC509458

7

14

15

42 ± 8 N·m

AC

10

9

16

4

1

11

5

17

4

18

42 ± 8 N·m

6

12

N

N

2

3

8

13

Disassembly steps

1.

Front seat reclining adjuster lever
cover

2.

Height adjuster lever cap <Except
Single cab>

3.

Height adjuster lever <Except
Single cab>

4.

Front seat side shield cover

5.

Inner seat belt

6.

Front seatback assembly

<<

A

>>

7.

Headrestraint guide

8.

Hog ling

9.

Front seatback cover

10. Front seatback pad
11. Front seatback frame
12. Front seat cushion assembly
13. Hog ling
14. Front seat cushion cover
15. Front seat cushion pad
16. Front seat side shield inner cover
17. Slide adjuster lever
18. Seat slide adjuster

Disassembly steps (Continued)

FRONT SEAT ASSEMBLY

INTERIOR

52A-25

<POWER SEAT>

AC509459

19

15

11

14

16

21

6

13

2

1

42 ± 8 N·m

AC

3

4

7

9

8

3

18

42 ± 8 N·m

10

20

N

N

5

12

17

Disassembly steps

1.

Front seat slide adjuster knob

2.

Front seat reclining adjuster knob

3.

Front seat side shield cover

4.

Front power seat switch

5.

Power seat switch bracket A

6.

Power seat switch bracket B

7.

Front seat motor cover

8.

Inner seat belt

9.

Front power seat harness

10. Front seatback assembly

<<

A

>>

11. Headrestraint guide

12. Hog ling
13. Front seatback cover
14. Front seatback pad
15. Front seatback Frame
16. Front seat cushion assembly
17. Hog ling
18. Front seat cushion cover
19. Front seat cushion pad
20. Front seat side shield inner cover
21. Seat slide adjuster

Disassembly steps (Continued)
