AC801599

AB

Grease: Molykote G-1023 (Dow Corning CO., LTD.) or equivalent

Grease application locations

Disassembly steps

1.

Sunroof drain bracket

2.

Sunroof sunshade

3.

Sunroof deflector

4.

Sunroof drip rail

5.

Sunroof sunshade stopper

<<

A

>>

>>

A

<<

6.

Sunroof lid slide guide

<<

B

>>

7.

Sunroof drove belt

8.

Sunroof housing

SUNROOF ASSEMBLY

BODY

42-232

REMOVAL SERVICE POINTS

<<A>> SUNROOF LID SLIDE GUIDE REMOVAL

AC801562AB

Sunroof housing

Marking

Sunroof lid slide guide

CAUTION

Before removing the sunroof lid slide guide rear-
ward, make the marking on the sunroof housing
as shown in the figure to indicate the sunroof lid
glass fully closed position.

<<B>> SUNROOF DRIVE BELT REMOVAL

AC801563AB

Sunroof drive belt

Sunroof lid
slide guide

CAUTION

Grease is applied to the sunroof drive belt. Pre-
vent dust from adhering to the surface because it
may cause abnormal noise or malfunction.
Slide the sunroof lid slide guide rearward, and
remove the sunroof drive belt from the guide.

INSTALLATION SERVICE POINT

>>A<< SUNROOF LID SLIDE GUIDE INSTALLA-
TION
1. Install the sunroof lid slide guide and the sunroof

drive belt to the sunroof housing.

2. Push in the sunroof lid slide guide and the sunroof

drive belt to the front side of the sunroof housing
until they stop.

SUNROOF ASSEMBLY

BODY

42-233

CAUTION

Position the sunroof lid slide guide properly, or
the sunroof may not operate normally.

AC801562AB

Sunroof housing

Marking

Sunroof lid slide guide

3. Set the sunroof lid slide guide to the position of

the marking on the sunroof housing made at
removal step as shown in the figure.

GREASE APPLICATION
Apply the grease to the sunroof drive cable, rotating
or sliding portions of functional parts (Refer to the fig-
ure entitled "Grease application locations").

Specified Grease: Molykote G-1023 (Dow
Corning CO., LTD.) or equivalent

BODY MOUNTING

BODY

42-234

BODY MOUNTING

REMOVAL AND INSTALLATION

M1421003700218

AC501255
AC501256

AC407105

AC505025

A

B

C

D

E

G

A

B

C

D

F

G

A

B

C

D

F

F

H

H

H

I

I

I

E

AG

1

1

1

6

6

6

2

2

2

7

7

7

3

3

3

4

4

4

5

5

5

8

8

8

9

9

10

10

10

10

10

11

11

11

47 ± 7 N·m

47 ± 7 N·m

47 ± 7 N·m

45 ± 5 N·m

E

8

10

11

45 ± 5 N·m

45 ± 5 N·m

45 ± 5 N·m

<Single cab>

G

N

N

N

N

N

N

N

AC501255

A

B

C

D

E

F

G

A

B

C

D

F

G

A

B

C

D

E

F

G

H

H

H

E

AE

1

1

1

6

6

2

2

2

7

7

7

3

3

3

4

4

4

5

5

5

8

8

8

9

9

10

10

10

10

10

11

11

11

47 ± 7 N·m

47 ± 7 N·m

47 ± 7 N·m

45 ± 5 N·m

45 ± 5 N·m

45 ± 5 N·m

<Club cab>

N

N

N

N

N

N

BODY MOUNTING

BODY

42-235
